Mitsui Seiki MODEL #JBD BRIDGE
Location:
Holland, OH
Manufacturer:
Mitsui seiki

Specifications

Condition:
used
Stock number:
13870
Table travel:
17"
Spindle feeds:
(6) .001 - .0102 IPR
Spindle taper:
#3 MT
Spindle speeds:
(12) 50 - 2100 RPM
Spindle stroke:
6-1/2"
Floor to table top:
31-1/2"
Table milling feeds:
1-7/8 & 3 IPM
Table area, t-slotted:
15" X 20"
Rail head cross travel:
14"
Spindle to table, min. / max:
0" / 18"
Subcategory:
Jig borer

Description

SERIAL #255
MODEL #JBD
TABLE AREA, T-SLOTTED .............. 15" X 20"
SPINDLE SPEEDS ..................... (12) 50 - 2100 RPM
SPINDLE FEEDS ...................... (6) .001 - .0102 IPR
SPINDLE STROKE ..................... 6-1/2"
SPINDLE TO TABLE, MIN. / MAX. ...... 0" / 18"
SPINDLE TAPER ...................... #3 MT
TABLE TRAVEL ....................... 17"
TABLE MILLING FEEDS ................ 1-7/8 & 3 IPM
RAIL HEAD CROSS TRAVEL ............. 14"
DISTANCE BETWEEN HOUSING UPRIGHTS .. 23"
FLOOR TO TABLE TOP ................. 31-1/2"
POWER RAIL ELEVATION, HEAD CROSS TRAVEL & TABLE TRAVERSE
HAND LEVER RAIL & TABLE CLAMPING
2-AXIS PATHFINDER DIGITAL READOUT
WORK LAMP
COOLANT
