5" CINCINNATI GILBERT TABLE TYPE HORIZONTAL BORING MILL in Holland, OH, USA

Top Seller
5" CINCINNATI GILBERT TABLE TYPE
Location:
Holland, OH, USA
Price:
No price

Specifications

Condition:
used
Stock number:
1777
Saddle travel:
96"
Spindle feeds:
(12) .002 TO .125 IPR
Spindle speeds:
(27) 15 TO 1500 RPM
Spindle travel:
36"
Taper in spindle:
#50 NS (POWER DRAW BAR)
Cross table travel:
72"
Diameter of spindle:
5"
Vertical travel of head:
60"
Working surface of table:
92" X 53"
Saddle, table & head feeds:
(24) .003 TO .250 IPR
Subcategory:
Boring machines

Description

SERIAL ........................... #J-122
WORKING SURFACE OF TABLE ......... 92" X 53"
DIAMETER OF SPINDLE .............. 5"
SPINDLE SPEEDS ................... (27) 15 TO 1500 RPM
SADDLE, TABLE & HEAD FEEDS ....... (24) .003 TO .250 IPR
SPINDLE FEEDS .................... (12) .002 TO .125 IPR
CROSS TABLE TRAVEL ............... 72"
SADDLE TRAVEL .................... 96"
VERTICAL TRAVEL OF HEAD .......... 60"
SPINDLE TRAVEL ................... 36"
TAPER IN SPINDLE ................. #50 NS (POWER DRAW BAR)
EQUIPPED WITH:
HARD REPLACEABLE BED AND SADDLE WAYS, OUTBOARD SUPPORT,
PENDANT CONTROL (FOR ALL OPERATIONS), POWER TABLE, SADDLE AND
SPINDLE CLAMPS
25 HORSEPOWER MAIN MOTOR
