Top Seller
45" Swing 100" Centers Sharp
Location:
Harrison, NJ
Price:
$110,600 USD
Manufacturer:
Sharp lathes
Model:
45100X Heavy Pattern
Distance between Centers:
100"

Specifications

Condition:
new
Stock number:
136769
Model 2:
45100X - Heavier Pattern Model
Age info:
NEW
Bed width:
32"
Main motor:
40 hp
Cross feeds:
0.0009" - 0.05 inch per revolution
Quill taper:
MT #6
Quill travel:
7.87"
Quill diameter:
5.75"
Swing over bed:
45"
Compound travel:
17.7"
Leadscrew pitch:
2 teeth per inch
Cross rapid feeds:
40 inch per minute
Long. rapid feeds:
80 inch per minute
Cross slide travel:
31.5"
Longitudinal feeds:
0.0018 - 0.1 inch per revolution
Spindle taper/bore:
A2-11 (6.02") is standard, or A2-15 (9.05")
Spindle speeds (18):
6 - 750 RPM
Swing over crosslide:
32"
Swing over gap, width:
65", 24"
Vari speed (optional):
18 - 1,000 RPM, 16 - 750 RPM, 12 - 400 RPM
Distance between centers:
100"
Net weight (approximately):
36,250 lbs
Subcategory:
New lathes
Subcategory 2:
Toolroom machines

Description

NEW SHARP BIG SPINDLE BORE PRECISION LATHE
MODEL: 45100X - Heavier Pattern Model
FEATURES
- Swing 35" - 70", center distance 60" - 200", spindle bore 6", 9",
& 12.5" (see our other listings for the full range of sizes)
- 18 spindle speeds, optional variable speed with 4 step changes
- Electromagnetic spindle brake
- Machine bed and base made out of one piece casting
- 6 way lever control of feed and rapid traverse for carriage, cross
slide & compound
- 240 threads for inch, metric, module and diametral pitch by
direct selection
- Additional hardened and ground way for support of apron
- Tailstock has Hi-Low gear for quill feed, also equipped with
"tang" and built-in stopper to help in heavy drilling
CAPACITY
Swing over bed: 45"
Swing over crosslide: 32"
Swing over gap, width: 65", 24"
Distance between centers: 100"
Bed width: 32"
HEADSTOCK
Spindle taper/bore: A2-11 (6.02") is standard, or A2-15 (9.05")
and A2-20 (12.51") are optional at extra cost
Spindle Speeds (18): 6 - 750 RPM
Vari speed (optional): 18 - 1,000 RPM, 16 - 750 RPM, 12 - 400 RPM
CARRIAGE
Cross slide travel: 31.5"
Compound travel: 17.7"
Longitudinal feeds: 0.0018 - 0.1 inch per revolution
Cross feeds: 0.0009" - 0.05 inch per revolution
Long. rapid feeds: 80 inch per minute
Cross rapid feeds: 40 inch per minute
Threads: metric: 1-56(60), inch: 1/2-28(60), module: 0.25-14(60), DP: 2-112 (60)
Leadscrew pitch: 2 teeth per inch
TAILSTOCK
Quill travel: 7.87"
Quill diameter: 5.75"
Quill taper: MT #6
GENERAL
Main motor: 40 hp
Net weight (approximately): 36,250 lbs
STANDARD EQUIPMENT
Spindle sleeve, coolant system with pump & hose, halogen work
light, dead centers (2), chip guard on compound, indexable (8
positions) 4 way toolpost, toolbox & tools.
OPTIONAL EQUIPMENT (Call for prices)
4-Jaw chuck, face plate, steady rest, rear chuck adaptor, taper
attachment, variable spindle speeds (4 steps), semi-automatic
threading and turning cycle, & constant surface speed.
