Top Seller
48.5" Arm 11.8" Column Sharp
Location:
Harrison, NJ
Price:
$21,240 USD
Manufacturer:
Sharp
Model:
RD-1230
Capacity:
1-1/2"
Weight:
4,950 lbs.

Specifications

Condition:
new
Stock number:
136882
Boring:
4-3/4"
Age info:
NEW
Boring 2:
3-3/8"
Drilling:
2-3/16"
Drilling 2:
1-5/8"
Coolant pump:
1/8 hp
Elevating motor:
1 hp
Main motor (hp):
5 hp (2 speed motor)
Capacity tapping:
1-1/2"
Stroke of spindle:
9-7/8"
Capacity tapping 2:
1"
Diameter of column:
11-13/16"
Dimensions of base:
67-11/16" x 27-15/16" x 6-1/2"
Radial drill model:
RD-1230 *MADE IN TAIWAN*
Taper hole in spindle:
#4MT
Clamping motor for arm:
1 hp
Travel of spindle head:
35"
Effective area of table:
27-5/8" x 19-5/8" x 15-3/4"
Elevating height of arm:
34-5/8"
Measurement (l x w x h):
80" x 39" x 89"
Approximate shipping weight:
4,950 lbs.
Feed of spindle (1 pr x steps):
0.002" x 0.006" x 3 steps
Subcategory:
New radial drills

Description

NEW SHARP 12" Column Diameter, 48.5" Arm
RADIAL DRILL MODEL: RD-1230 *MADE IN TAIWAN*
SPECIFICATIONS
Diameter of column: 11-13/16"
Distance from column surface to spindle center, max: 48-1/2"
Distance from column surface to spindle center, min: 13-3/8"
Travel of spindle head: 35"
Distance from base surface to spindle end, max: 54"
Distance from base surface to spindle end, min: 19-3/8"
Elevating height of arm: 34-5/8"
Effective area of table: 27-5/8" x 19-5/8" x 15-3/4"
Dimensions of base: 67-11/16" x 27-15/16" x 6-1/2"
Taper hole in spindle: #4MT
Stroke of spindle: 9-7/8"
RPM of spindle (RPM range x steps) 44 - 1500 x 12 steps
Feed of spindle (1 PR x steps): 0.002" x 0.006" x 3 steps
Main motor (hp): 5 hp (2 speed motor)
Elevating motor: 1 hp
Clamping motor for column and gear-box: 1 hp
Clamping motor for arm: 1 hp
Coolant pump: 1/8 hp
Measurement (L x W x H): 80" x 39" x 89"
Approximate shipping weight: 4,950 lbs.
CAST IRON
Drilling: 2-3/16"
Capacity tapping: 1-1/2"
Boring: 4-3/4"
STEEL
Drilling: 1-5/8"
Capacity tapping: 1"
Boring: 3-3/8"
