Top Seller
63" Arm 17" Column Sharp
Location:
Harrison, NJ
Price:
$41,690 USD
Manufacturer:
Sharp
Model:
RD-1600
Capacity:
2-3/8"
Weight:
11,220 lbs.

Specifications

Condition:
new
Stock number:
136883
Boring:
7-3/8"
D model:
RD-1600 **MADE IN TAIWAN**
Age info:
NEW
Boring 2:
5"
Drilling:
2-5/8"
Drilling 2:
2-1/4"
Coolant pump:
1/8 hp
Elevating motor:
2 hp
Main motor (hp):
7-1/2 hp
Capacity tapping:
2-3/8"
Stroke of spindle:
14-9/16"
Capacity tapping 2:
2"
Diameter of column:
17"
Dimensions of base:
97-5/8" x 41-11/32" x 8-1/4"
Taper hole in spindle:
#5MT
Clamping motor for arm:
1/2 hp
Travel of spindle head:
49-5/8"
Effective area of table:
27-5/8" x 19-5/8" x 15-3/4"
Elevating height of arm:
35-7/16"
Measurement (l x w x h):
114" x 56" x 115"
Approximate shipping weight:
11,220 lbs.
Feed of spindle (1 pr x steps):
0.003" x 0.038" x 6 steps
Machine height from floor, max:
124-56/64"
Subcategory:
New radial drills

Description

NEW SHARP RADIAL DRILL - 17" Column 63" Arm
d MODEL: RD-1600 **MADE IN TAIWAN**
(note - photo is of model RD-1230)
Diameter of column: 17"
Distance from column surface to spindle center, max: 63"
Distance from column surface to spindle center, min: 13-3/8"
Travel of spindle head: 49-5/8"
Distance from base surface to spindle end, max: 63"
Distance from base surface to spindle end, min: 13"
Elevating height of arm: 35-7/16"
Effective area of table: 27-5/8" x 19-5/8" x 15-3/4"
Dimensions of base: 97-5/8" x 41-11/32" x 8-1/4"
Taper hole in spindle: #5MT
Stroke of spindle: 14-9/16"
RPM of spindle (RPM range x steps) 40 - 1920 x 12 steps
Feed of spindle (1 PR x steps): 0.003" x 0.038" x 6 steps
Main motor (hp): 7-1/2 hp
Elevating motor: 2 hp
Clamping motor for column and gear-box: 1 hp
Clamping motor for arm: 1/2 hp
Coolant pump: 1/8 hp
Machine height from floor, max: 124-56/64"
Measurement (L x W x H): 114" x 56" x 115"
Approximate shipping weight: 11,220 lbs.
CAST IRON
Drilling: 2-5/8"
Capacity tapping: 2-3/8"
Boring: 7-3/8"
STEEL
Drilling: 2-1/4"
Capacity tapping: 2"
Boring: 5"
