Top Seller
10" Blade Dia 1.2hp HP
Location:
Harrison, NJ
Manufacturer:
Dake saws
Model:
Cut 250 Manual *Made in Italy*
Motor:
1.2
Weight:
378

Specifications

Condition:
new
Stock number:
153208
Phase:
1
Speeds:
44
Weight:
378
Voltage:
110-volt
Age info:
NEW
C height:
61"
A work height:
37"
Motor horsepower:
1.2
Maximum blade diameter:
10
D floor space left to right:
21"
E floor space front to back:
20-1/4"
Tube 45˚ capacity (inches):
2-3/8
Tube 90˚ capacity (inches):
2-3/4
Square 45˚ capacity (inches):
2-1/8
Square 90˚ capacity (inches):
2-1/2
B overall front to back head up:
35"
Rectangle 45˚ capacity (inches):
2-1/2 x 1-7/8
Rectangle 90˚ capacity (inches):
3-7/8 x 1-3/4
Solid round 45˚ capacity (inches):
1
Solid round 90˚ capacity (inches):
1-1/4
Subcategory:
New cold saws

Description

DAKE CUT 250
MANUAL COLD SAW
*MADE IN ITALY*
The Dake Cut 250 model manual cold saw uses up to 10" circular cold saw blades, has a 1.2 hp motor, and mounts on an included pedestal that houses a built-in coolant tank and pump. The blade rotates at 44 rpm. The saw head pivots up and down to cut, and rotates 45 degrees to the right and left of center for miter cuts. The saw drive has an oversized steel spindle and a tapered bronze roller bearing gear assembly for heavy-duty use. The hardened and ground spindle shaft has ball bearing support for reliability. The saw is wired for single-phase, 110 volt AC operation.
FEATURES
Head rotates 45° right and left of center for mitering.
Dependable oversized spindle and gear assembly with steel spindle and bronze gear.
Bronze gear with tapered roller bearing support.
Reliable mechanical coolant pump with flow control adjustment.
Adjustable hinged pivot.
Additional ball bearing support of hardened and ground spindle shaft to prevent failure.
STANDARD EQUIPMENT
Blade
Pedestal base
Tool kit
Gallon of coolant
Adjustable positive stop
SPECIFICATIONS
Maximum blade diameter ............................ 10
Motor horsepower .................................. 1.2
Voltage ........................................... 110-volt
Phase ............................................. 1
Speeds ............................................ 44
Weight ............................................ 378
Solid round 90˚ capacity (inches) ................. 1-1/4
Solid round 45˚ capacity (inches) ................. 1
Tube 90˚ capacity (inches) ........................ 2-3/4
Tube 45˚ capacity (inches) ........................ 2-3/8
Square 90˚ capacity (inches) ...................... 2-1/2
Square 45˚ capacity (inches) ...................... 2-1/8
Rectangle 90˚ capacity (inches) ................... 3-7/8 x 1-3/4
Rectangle 45˚ capacity (inches) ................... 2-1/2 x 1-7/8
DIMENSIONS
A Work height ..................................... 37"
B Overall front to back head up ................... 35"
C Height .......................................... 61"
D Floor space left to right ....................... 21"
E Floor space front to back ....................... 20-1/4"
