Location:
Navasota, TX
Model:
FSG 2A 818
Weight:
2,907 Lbs.

Specifications

Condition:
used
Stock number:
G802536
Coolant:
Yes
Main motor:
3 Hp. 220 /440
Net weight:
2,907 Lbs.
Floor space:
86.6" X 62" X 76.7"
Condition info:
Very Good
Coolant guards:
Yes
Cross travel manual:
9-1/2"
Cross travel rapids:
11-3/4"
Longitudinal manual:
20.87"
Magnetic chuck size:
8" X 18"
Grinding wheel speeds:
2,850 Rpm's
Cross travel automatic:
9"
Longitudinal automatic:
19-3/4"
Over the wheel dresser:
Yes
Vertical working height:
18"
Rapid traverse up & down:
Yes
Wheel head automatic feed:
.016 To .24
Wheel head rapid traverse:
13 IPM
Rapid traverse long & cross:
48" IPM
Standard size grinding wheel:
8" X 1/2" X 1-1/4" Bore
Wheel head mirco-feed revolution:
.01
Longitudinal table speed hydraulic:
16 To 82 FPM
Wheel head hand wheel per graduation:
.0005
Wheel head hand wheel per revolution:
.01
Wheel head mirco-feed per graduation:
.0002
Max distance table to center of spindle:
17-3/4"
Subcategory:
Grinders

Description

Magnetic Chuck Size 8" X 18"
Longitudinal Automatic 19-3/4"
Longitudinal Manual 20.87"
Longitudinal Table Speed Hydraulic 16 To 82 FPM
Max Distance Table To Center Of Spindle 17-3/4"
Rapid Traverse Long & Cross 48" IPM
Cross Travel Automatic 9"
Cross Travel Manual 9-1/2"
Cross Travel Rapids 11-3/4"
Wheel Head Automatic Feed .016 To .24
Wheel Head Rapid Traverse 13 IPM
Wheel Head Hand Wheel Per Revolution .01
Wheel Head Hand Wheel Per Graduation .0005
Wheel Head Mirco-Feed Revolution .01
Wheel Head Mirco-Feed Per Graduation .0002
Vertical Working Height 18"
Standard Size Grinding Wheel 8" X 1/2" X 1-1/4" Bore
Grinding Wheel Speeds 2,850 Rpm's
Main Motor 5 Hp. 220 /440
Net Weight 2,907 Lbs.
Floor Space 86.6" X 62" X 76.7"
Coolant Yes
Coolant Guards Yes
Over The Wheel Dresser Yes
Eelectromatic Neutrofier For Chuck Yes
Rapid Traverse Up & Down Yes
Note: Machine Has Been Cleaned, Painted & Cycled.
Condition Very Good
