Location:
Gensingen, Germany
Manufacturer:
Weiler lathes
Model:
160 CNC

Specifications

Condition:
used
Year:
1986
Control:
Bosch CC 200T, CNC railway control
Type of machine:
CNC Turning Machines
Machine in stock:
Yes

Description

CNC Turning Machines Weiler 160 CNC
used machine
Numerically controlled lathe
Technical data:
WORKSPACE
Spindle passage 41 mm
Bar passage 32 mm
Chuck 140 mm
Spindle nose Gr. 5
Circular diameter 240 mm
Spindle hight above floor 1100 mm
LINEAR TOOL SYSTEM
Longitudinal travel with Chuck Z-max. 350mm
Plan travel x-max 250 mm
Turning diameter over linear plate 50 mm
Longitudinal travel with support tailstock 325 mm
AUTOMATIC 4-POSITION TOOL TURRET
QUICK-CHANGE HOLDER MULTIFIX GR. B HAND REVOLVER READY GR. 1
FEED DRIVE
Rapid traverse x and Z-axis 5000 mm / min
Feed x and Z axis 4000mm / min
Diameter and pitch of the ballscrew X-axis diam 25 x 5 mm
Diameter and pitch the ball spindle Z-axis diam 32 x 5 mm
Machine:
1940 x 1120 mm footprint
Largest height 1800mm
Weight max. 1300kg
Max. Power Consumption 11kW
Painting green RAL 6011
Control: Bosch CC 200T, CNC railway control
Maschinenn No. 162
Built in 1986
Accessories:
Angst PAFIX tapping heads
Roehm lathe chuck size 140/3
Papers: machine card, instruction manual, test report, manual control, wiring diagram
