Location:
Navasota, TX
Manufacturer:
W F Well
Model:
W-9
Motor:
3 Hp.
Weight:
990 Lbs.

Specifications

Condition:
used
Year:
1986
Serial number:
86-4199
Stock number:
S065339
Weight:
990 Lbs.
Coolant:
Yes
Blade size:
1" x .035 X 11'6"
Main motor:
3 Hp.
Blade speed:
70 To 300 FPM
Work height:
26"
Sawing force:
30 To 120 Lbs.
Condition info:
Good
Machine height:
63"
Discharge table:
No
Manual clamping:
Yes
Weight capacity:
2,000 Lbs.
Blade wheel size:
14-1/2"
Coolant capacity:
10 Gallon
Machine dimension:
81" X 43"
Hydraulic capacity:
3/4 Gallon
Hydraulic power down:
Yes
Maximum capacity flat:
17"
Maximum capacity round:
9"
Rectangular at 45 degrees:
9" X 8" Wide
Rectangular at 90 degrees:
9"" X 17" Wide
Manual in feed of material:
Yes
Subcategory:
Horizontal

Description

Maximum Capacity Round 9"
Maximum Capacity Flat 17"
Rectangular At 90 Degrees 9"" X 17" Wide
Rectangular At 45 Degrees 9" X 8" Wide
Work Height 26"
Weight Capacity 2,000 Lbs.
Blade Wheel Size 14-1/2"
Blade Size 1" x .035 X 11'6"
Blade Speed 70 To 300 FPM
Sawing Force 30 To 120 Lbs.
Main Motor 3 Hp.
Weight 990 Lbs.
Machine Dimension 81" X 43"
Machine Height 63"
Coolant Capacity 10 Gallon
Hydraulic Capacity 3/4 Gallon
Manual Clamping Yes
Hydraulic Power Down Yes
Coolant Yes
Manual In Feed Of Material Yes
Discharge Table No
Note: Machine Will Be Cleaned, Painted And
Cycled.
Condition Good
