Anritsu MS2723C in United States
Location:
United States
Price:
$8,000 USD
Model:
MS2723C

Specifications

Condition:
used
Stock number:
–120 dBm to +30 dBm
Gps:
SMA Female
Rf in:
Type N, female, 50 Ω, Maximum Input +30 dBm, ± 50 VDC
50 mhz:
–54 dBc
If out:
BNC, female, 50 Ω, 140 MHz
2.4 ghz:
+15 dBm
< 4 ghz:
+5 dBm typical
> 4 ghz:
–75 dBc typical
Division:
Test and Measurement
< 4 ghz 2:
–60 dBc typical
Detection:
Peak, RMS/Avg, Negative, Sample, Quasi-peak
Sweep mode:
Fast, Performance, No FFT
Sweep time:
10 µs to 600 seconds in zero span
Headset jack:
2.5 mm barrel connector
Marker types:
Style (Fixed/Tracking), Noise Marker, Frequency Counter Marker
Display range:
1 to 15 dB/div in 1 dB steps, ten divisions displayed
Dynamic range:
> 104 dB @ 2.4 GHz, 2/3 (TOI-DANL) in 1 Hz RBW
Usb interface:
5-pin mini-B, Connect to PC for data transfer
External power:
5.5 mm barrel connector, 12 to 15 VDC, < 5.0 Amps
Frequency span:
10 Hz to 13 GHz including zero span
Lan connection:
RJ48C, 10/100 Mbps, Connect to PC or LAN for Remote Access
4 ghz to 13 ghz:
+12 dBm typical
Amplitude range:
DANL to 30 dBm
Frequency range:
9 kHz to 13 GHz (usable to 0 Hz), Preamp 100 kHz to 13 GHz
50 mhz to 13 ghz:
+20 dBm typical
External trigger:
BNC, female, 50 Ω, Maximum Input ± 5 VDC
Measurement range:
DANL to +30 dBm
Tuning resolution:
1 Hz
Usb interface (2):
Type A, Connect Flash Drive and Power Sensor
Smart measurements:
Field Strength (uses antenna calibration tables to measure dBm/m
Limit line advanced:
Type (Absolute/Relative), Mirror, Save/Recall
Attenuator resolution:
0 to 65 dB, 5 dB steps
External reference in:
BNC, female, 50 Ω, Maximum Input +10 dBm
Video bandwidth (vbw):
1 Hz to 10 MHz in 1–3 sequence (–3 dB bandwidth)
External reference out:
BNC, female, 50 Ω, 10 MHz
Low end frequency limit:
9.00 kHz
High end frequency limit:
13.00 GHz
Resolution bandwidth max:
10.00 MHz
Resolution bandwidth min:
1 Hz
Resolution bandwidth (rbw):
1 Hz to 10 MHz in 1–3 sequence ± 10% (–3 dB bandwidth)
Rbw with quasi-peak detection:
200 Hz, 9 KHz, 120 kHz (–6 dB bandwidth)
Vbw with quasi-peak detection:
Auto VBW is On, RBW/VBW = 1
Subcategory:
Anritsu
Subcategory 2:
Analyzers spectrum

Description

Anritsu MS2723C Portable Spectrum Analyzer ** Cal & in Stock**
The Spectrum Master MS2723C features over 30 analyzers in one to meet virtually every measurement need. In addition to spectrum analysis a user can select optional capabilities and analyzers including:
- High Accuracy Power Meter
- Interference Analyzer
- Channel Scanner
- 140 MHz Zero-Span IF Output, 30 MHz bandwidth
- GPS Receiver
- Increase frequency accuracy, geo-tag data collection
- Secure data operation
- 3GPP Signal Analyzers
For post processing data collected on your instrument utilize Master Software Tools – a PC program included with the instrument. It provides powerful data analysis tools for spectrum clearing and interference monitoring. And the Remote Access Tool allows the user to see and control the instrument over a LAN connection.
Continuous frequency coverage from 9 kHz to 13 GHz gives the wireless professional the performance needed for the most demanding measurements. Whether your application is spectrum monitoring, hidden signal detection, RF and microwave signal measurements, microwave backhaul testing or cellular signal measurements, the Spectrum Master MS2723C gives you the tools you need to make the job easier and more productive.
Options:
019-
High Accuracy Power Meter
025-
Interface Analyze
The latest generation of Anritsu handheld spectrum analyzers includes the
MS2723C
Spectrum Master. This high performance spectrum analyzer offers exciting new features and options, which bring more value to the user over our previous generations:
Frequency Coverage - 9 kHz to 13 GHz
Broadband preamplifiers over the whole frequency range for increased sensitivity around 20 dB
Three Sweep Modes – with improved Sweep Speed - up to 100 times faster
Resolution Bandwidths from 1 Hz to 10 MHz
New triggering choices including hysteresis, hold-off, and delay
More zero-span capabilities including 10 MHz RBW & VBW
Enhanced Spectrum Analyzer GUI including large marker display choice
Choice of display options for readability – normal, black and white, night vision, high contrast
On-screen Interference Mapping as part of the Interference Analysis option
LTE Measurements up to 20 MHz
30 MHz Wide Zero-Span IF Output at 140 MHz center frequency for external demodulation of virtually any other wideband signal
The Spectrum Master MS2723C features over 30 analyzers in one to meet virtually every measurement need. In addition to spectrum analysis a user can select optional capabilities and analyzers including:
High Accuracy Power Meter
Interference Analyzer
Channel Scanner
140 MHz Zero-Span IF Output, 30 MHz bandwidth
GPS Receiver
Increased frequency accuracy, geo-tag data collection
Secure data operation
3GPP Signal Analyzers
LTE, GSM/EDGE, W-CDMA/HSPA+, TD-SCDMA/HSDPA
3GPP2 Signal Analyzers
CDMA2000 1X, CDMA2000 1xEV-DO
IEEE 802.16 Signal Analyzers
Fixed WiMAX, Mobile WiMAX
For the post processing data collected on your instrument, use the Master Software Tools included with the instrument
