2016 PROMAX STAR مصنع C45-PN
Location:
Ankara, Turkey
Price:
$67,423 USD
Manufacturer:
PROMAX STAR
Model:
مصنع C45-PN موبايل، الخرسانة المتنقلة الخلط

Specifications

Condition:
used
Year:
2016
Colour:
blue
Capacity:
45 m3/h
In stock:
3
Original painting:
yes
Vehicle condition:
new
First registration:
2016
Registration number:
1
Originally varnished:
yes
Subcategory:
Concrete plant

Description

PROMAXSTAR CONCRETE BATCHING PLANT LTD. CO.
quality solutions at affordable prices’
In more than 10 conturies More than 180 plant.
HIGH QUALITY
SPECIAL PRICE : 116.000 USD .
STATIONARY CONCRETE BATCHING PLANT
Manufacturer : PROMAXSTAR/TURKEY
Model : SB 60 -SNG
Capacity : 60 m3 / hour WET SYSTEM
Mixer :1m3 Single shaft mixer
TECHNICAL PROPERTIES
Capacity : 60 m3 / hour compacted fresh concrete
Mixer Capacity : 1000 Lt . ( compacted fresh concrete )
Total Motor Power Rating : 120 kW
Voltage : 380 V - 50 Hz
aggregate bunker
Capacity : 80 m3 - 4 x 20 m3
Aggregate hopper : 4
Discharing gate :4
Vibrator :3 x ozb 350/3
Pneumatic piston :4x 100x300 FMS
Aggregate weithing bent
Belt Diamation : 800x11,500 mm
Capasity : 5.000 kg
Engine – gearbox : gamak 15 kw –dissan dg 2-200
Load cell : 4x5000 kg zemic
Bent brand: DERBY.
conveyor
Belt Dimensions : 800 mm x 24,000 mm
Belt Brand : DERBY.
Engine – Gearbox : 22 kw dissan dg 2-250 k
tape and covered walkways available.
Cement Bunker
Weighing Capacity : 900 kg
Loadcell : 3 x 1000 kg ZEMIC
Discharge valve : 300 mm(wam- ozb)
Vibrator : 100/3 ozb
Water Weighing Bunker
Weighing Capacity : 400 lt
Loadcell : 3 unit 1000 kg ZEMIC
Discharge valve : 150 mm (wam-ozb)
Filling : 3 inc steel pipe and 3 inc penuematic valve TORK .
Water pump : 60 ton/h DOMAK .
Additive Bunker :
Capacity : 40 kg
Loadcell : 1x S type 100 kg ZEMIC
Discharge valve : 1 inc TORK
Compressor and air system
Compressor : AKKOMP (air manufacturer made in ITALY )
Tank capasity : 500 LT
Working Pressure : 8 ,5 bar
Motor Power Rating : 7,5 kw
Complete installation of steel and 4 storage tanks available.
Mixer
2000/1000 LT SINGLE SHAFT MIXER
Manufacturer : PROMAXSTAR /TURKEY
Type : 2000/1000 lt SINGLE SHAFT
Loading Capasity : 2000 lt.
Compacted Concrete Capasity : 1000 lt.
Electric engine :1x 37 kw Gamak
Gearbox :1x Yilmaz 37-96 mr 772
Central Lubrication System Brand : ILC (made in italy)
Mixer body Plates : Manganese ( it can manufacture 50.000m3-450.000m3)
Mixer Internal Linings (Wear Plates) : Ni- hard special hard cast material
Mixer Mixing Arm Materials : Ni- hard special hard cast material
Discharging in Emergency Situations : manual Emergency Situation hand pump
Emergency Stop Button available.
Digital Mixer Control System (alarm)
Automatic lubrication system monitor feature on pc
Control System
Full automatic pc - plc – printer - batcman.
unlimited users
remote access
unlimited prescriptions and customer registration
retrospective reporting
English- Russian- French- Arabic languages are available.
siemens- back off - Telemecanique – HES
Fore more information,pleas conctac us.
