2003 FRIULMAC RANDOMAT-E END MATCHER/TENONER

2003 FRIULMAC RANDOMAT-E END MATCHER/TENONER [EM-280007] in United States

Location:
United States
Price:
$32,900 USD
Manufacturer:
FRIULMAC
Model:
RANDOMAT-E

Specifications

Condition:
used
Year:
2003
Recnum:
EM-280007
Comments:
Light Use FRIULMAC "Rondamat" - in last (4) years, maybe (40) hours maximum!
Machtype:
END MATCHER/TENONER
Condition info:
(6-8) Very good condition [7]
Current status:
Active
Elect./voltage:
460 V, 60 Cy, 3 Ph.
Appr. repl. cost:
140000
Category:
End matchers

Description

FRIULMAC Randomat E End Matcher/Tenoner.

-- For end matching flooring or tenoning cabinet & entry door rails; feed through system allows continuous feeding of random length parts with any kind of profile.Specifications & Capacity:

-- 1-3/16" Min. - 9-7/8" max. width cap., 6-5/16" min. - 120" max. length (longer lengths with additional support); 3/8" min. - 1-3/16" max. thickness cap.

-- Approx. (10 - 14) cycles/Min depending on part length.

-- Shaper Heads: Twin 7.5 HP - 5,700 RPM high speed shaper motors, 40 mm spindle dia., spindles pneumatically traverse in tandom for each cutting cycle.

-- Feed system with: (2) 98" Long x 10" wide powered in- & outfeed belt conveyors, (2) 1.5 HP feed motors with inverter control.

-- Parts are automatically fed & positioned with sensors and a positive stop to the 1st vertical shaper head (a 2nd shaper head is next to the 1st one); cope cycle is automatic.

-- Parts are conveyed past the 1st & 2nd shaper head, automatically reversed & positioned to a positive stop for the 2nd cut on the other end of the part. At the same time the 1st shaper head would be coping the 1st end of another part.Operator & Machine Controls:

-- PLC Controlled conveyor & shaper cut cycle for automatic operation, variable feed speed conveyor line, and shaper head advance with LED readout on the controls.

-- Cutting Station with: Overhead holddown wheels & 4-point pneumatic clamping with (2) overhead & (2) horizontal clamps.

-- NOTE: Will include dust collection up to the blast/closing gate.High speed, CNC controlled, Endmatcher for flooring, doors, waiscoat, T&G ceilings; will produce 13,000 ft of end-flooring in an 8-hour shift.Previous owner states the following: Lightly Used FRIULMAC “RONDAMAT�, last used on April 8, 2015 to complete a flooring job. All functions are in good working order. Includes 2 heads, extra spindle, Manuals, Dust Collection Manifold up to the blast/closing gate. Will Include electrical pigtail - about 4' long.
