Location:
Navasota, TX
Manufacturer:
Jones & Lamson
Model:
10 A
Spindle Nose:
A-11

Specifications

Condition:
used
Year:
1954
Serial number:
70398
Stock number:
L630421
Feeds:
.005 To .100 I.P.R.
Weight:
14,000 Lbs.
Coolant:
Yes
Chuck size:
18" 3- Jaw With 2 Piece Jaws
Main motor:
30 Hp.
Spindle hole:
6-1/2"
Spindle nose:
A-11
Condition info:
Good
Flange holders:
5
Spindle speeds:
12 To 600 Rpm's
Center distance:
70"
Fixed rear turret:
Yes
Slide tool holders:
1
Swing over bed ways:
32"
Tool post 4 way on front:
Yes
Rapid traverse front and rear:
Yes
Swing over cross slide carriage:
22"
Subcategory:
Turret saddle type

Description

Swing Over Bed Ways 32"
Swing Over Cross Slide Carriage 22"
Center Distance 70"
Spindle Hole 6-1/2"
Spindle Speeds 12 To 600 Rpm's
Spindle Nose A-11
Chuck Size 18" 3- Jaw With 2 Piece Jaws
Feeds .005 To .100 I.P.R.
Main Motor 30 Hp.
Flange Holders 5
Slide Tool Holders 1
Weight 14,000 Lbs.
Coolant Yes
Tool Post 4 Way On Front Yes
Rapid Traverse Front And Rear Yes
Fixed Rear Turret Yes
Note: Machine Has Just Came In. Machine Will Be
Cleaned, Painted And Cycled.
Condition Very Good
