Location:
Navasota, TX
Model:
Series Il
Spindle Taper:
# 300 Universal Kwik Switch

Specifications

Condition:
used
Stock number:
M282427
Weight:
5,500 Lbs.
T- slots:
3 @ 2-1/2"
Main motor:
4 Hp.
Ram travel:
16"
Table load:
1,500 Lbs.
Table size:
11" X 58"
Chrome knee:
Yes
Knee travel:
16"
Spindle tilt:
+/- 45 Degrees
T-slott size:
5/8"
Spindle feeds:
.06 To 2.50 IPM
Spindle taper:
# 300 Universal Kwik Switch
Condition info:
Very Good
Machine height:
100"
Spindle swivel:
+/- 60 Degrees
Height above floor:
48-3/4"
Table travel cross:
31"
Spindle quill travel:
5"
Rapid feed rate z axis:
12 IPM
Saddle travel in & out:
16"
Boring range mild steel:
8" Maximum
Milling feed rates z axis:
3/16 To 12 IPM
Milling capacity mild mild:
4"
Rapid feed rate x & y axis:
24 IPM
Spindle to table min / max:
10-1/2" To 26-1/2"
Milling feed rates x & y axis:
3/8 To 24 IPM
Spindle speeds variable low range:
50 To 450 Rpm's
Drilling capacity mild steel power:
3/4"
Spindle speeds variable high range:
450 To 3,500 Rpm's
Drilling capacity mild steel manual:
1-1/4"
Power tool lock (will be installed):
Yes
Floor space left to right / front to back:
78" X 74"
Subcategory:
Mills
Subcategory 2:
Knee type

Description

Table Size 11" X58"
Spindle Taper Universal Kwik Switch
Spindle Speeds Variable 50 To 3,500 Rpm's
Spindle Feeds .0 To .240 IPM
Spindle Quill Travel 5"
Spindle Tilt +/- 45 Degrees
Spindle Swivel +/- 45 Degrees
Spindle To Table Min / Max 6-3/4" / 18-3/4"
Saddle Travel In & Out 16"
Table Travel Cross 30"
Knee Travel 16"
Table / Knee Feeds .075 To .150 I.P.R.
Main Motor 4 Hp.
Weight 6,500 Lbs.
Floor Space Left To Right / Front To Back 74" X 74"
Machine Height 100"
Chrome Knee Yes
Power Tool Lock Yes
Note: Machine Will Be Cleaned, Painted And
Cycled. From Government Surplus.
Condition Very Good
