Location:
Lincolnshire, IL
Weight:
6,500 Lbs.

Specifications

Condition:
used
Year:
1978
Stock number:
33203
Wheel size:
12" X 1-1/2" X 3"
Wheel speed:
1800 RPM
Approximate weight:
6,500 Lbs.
Spindle drive motor:
5 HP (A.C. Direct Drive)
Work size - maximum:
12" X 19" X 36"
Cross travel - maximum:
14"
Spindle down feed rates:
0.0001" To .003" (Variable)
Vertical travel - maximum:
19-1/4"
Rapid traverse rate - cross:
150 IPM
Hydraulic feed rates - cross:
0.010" to .500" (Variable)
Rapid traverse rate - vertical:
40 IPM
Hydraulic feed rates - longitudinal:
10 to 90 FPM (Variable)
Longitudinal table travel - maximum:
41"

Description

Serial No. 523-1236-264 New - 1978
SPECIFICATIONS:
At Each Reversal of Power Longitudinal Table Travel
EQUIPPED WITH:
12" X 36" Magnetic Chuck
Electro Magnetic Neutrofier with Remote Station
Incremental Downfeed for Automatic Slot or Surface Grinding to Positive Stop
Hydraulic Longitudinal and Cross Feeds
Rapid Vertical Positioning
Automatic Lubrication System
Rear Auxiliary Fan for Heat Dispersion
*Preliminary Specifications Subject to Verification.
