Location:
Lincolnshire, IL
Manufacturer:
N/A
Weight:
2,450 Lbs.

Specifications

Condition:
used
Year:
1987
Stock number:
29777
Electrical:
380V / 50 Hz
Grinding range:
20" x 9"
Approximate weight:
2,450 Lbs.
Spindle drive motor:
5.5HP
Table clamping size:
27-1/2" x 7-1/2"
Workpiece - maximum:
20"L x 9"W x 9-3/4"H
Size of grinding wheel:
4" x 9-3/4"
Grinding wheel speeds - 4 steps:
1,450 RPM - 2,560RPM
Approximate dimensions - machine:
84"L X 60"W X 100"H
Aproxinmte dimensions - coolant system:
40"L x 36"W x 36"H
Table speeds - hydraulic infinitely variable:
0 - 390 IPM

Description

Serial No. 9203 New - 1987
SPECIFICATIONS:
EQUIPPED WITH:
Fine Infeed Using Handwheel
Hydraulic Coarse Adjustment of Grinding Head (Lifting and Lowering)
Grinding Wheel Dressing Device, Swivel-In, Mounted on Grinding Wheel Hood
6-3/4" x 17-3/4" Magnetic Chuck
Through Spindle Coolant System
*Preliminary Specifications Subject to Verification.
