Location:
Lincolnshire, IL
Manufacturer:
N/A
Stroke:
14.3" / 365 mm

Specifications

Condition:
used
Year:
1989
Stock number:
25484
Daylight:
21.8" / 555*1070 mm
Pressing:
1.279" Second / 32.5 mm/s
Ram area:
39.37" x 31.5" / 1000*800 mm^2
Ram stroke:
14.3" / 365 mm
Table area:
39.37" x 31.5" / 1000*800 mm
Drive power:
20 HP / 15 kW
Fast advance:
174 IPM/14.055" Second / 357 mm/s
Table height:
33.5" / 850 mm
Stopping time:
0.081 Seconds
Catalog weight:
17,000 Lbs. / 7500 kg
Safety distance:
129 mm
Machine volatage:
230/460/3/60
Retract - maximum:
8.937" Second / 227 mm/s
Pressure - maximum:
110 Tons / 1000 kN
Stroke stop distance:
18 mm
Oil pressure- maximum:
252 bar
Subcategory:
Presses, hydraulic

Description

Serial No. 13451 New-1989
SPECIFICATIONS:
Ram Speeds
Stroke Stop Measurement
EQUIPPED WITH:
Siemens Simatic OP396 Programmable Controller
Hydraulic Tool Clamping
Digital Stroke Control and Ram Force Control
Six Position Cycle Selector Control
2-Hand Safety Control
Pressure, Time, Stroke Dep., Stroke Conversion
One Cycle, Two Cycle and Protection Functions
OKAL Air-Oil Cooler
*Preliminary Specifications Subject to Verification.
