Location:
Indian Trail, NC
Manufacturer:
Mazak lathes
Model:
M-5N
Spindle Bore:
4.09"
Spindle Nose:
A2-15

Specifications

Condition:
used
Year:
2007
Serial number:
195906
Stock number:
1915
Spindle bore:
4.09"
Spindle nose:
A2-15
Maximum speed:
2200 RPM
Maximum swing:
24.02"
Spindle drive:
25 HP / 30 HP AC
X-axis travel:
22.05"
Z-axis travel:
80.91"
Machine weight:
14,740 lbs.
Tailstock quill travel:
5.12"
Maximum machining length:
81.89"
Tailstock quill diameter:
3.9"
Maximum machining diameter:
22.83"
Subcategory:
Lathes cnc

Description

Equipped With:
Mazatrol 640T CNC Control*20.75" Kitagawa 3-Jaw Chuck with 5.5"Hole*8-Position Front Vertical Turret*6-Position Rear Horizontal Turret*Steady Rest*Programmable Tailstock*Live Center*Jorgensen Chip Conveyor*Electric Foot Switch*Tooling*Inspect in Plant Under Power ( Very Low Hours)
