Location:
Ivyland, PA
Manufacturer:
Sunnen
Model:
VM 20
Weight:
11,000 lbs

Specifications

Condition:
used
Stock number:
5778
Net weight:
11,000 lbs
Spindle speed:
50 - 8,000
Spindle taper:
Cat 40
Feed rate range:
0.1 - 800 ipm
Electrical system:
220 volt 3ph
Table size (l x w):
45 x 20"
Max weight on table:
2,000 lbs
Accuracy: positioning:
.0002"
Accuracy: repeatability:
.00015"
Cross traverse (y-axis):
20"
Table traverse (x-axis):
40"
Spindle center to column:
21.5"
Spindle nose to table height:
35
Rapid traverse (x-y & z axis):
1,000 ipm
Vertical head travel (z-axis):
26"
Boring range (various tooling ):
0.98 - 6"
Work space required (w x d x h):
112 x 110 x 120"
Main spindle motor (int/continous):
24/15 hp
Max boring depth (various tooling):
10.43"
Subcategory:
Cnc machines

Description

Equipped With:
16 TOOL HOLDER CENTURION 7 CONTROL Tooling: Machine set for V-8 Blocks Nissan Block Fixture Universal Block Adaptor Large Boring Bar Small Boring Bar End Mill Holders Probe for probing Bores Electronic User Manual for Milltronics V-20 base Machine
