Location:
Navasota, TX
Manufacturer:
King lathes
Model:
360021-4

Specifications

Condition:
used
Year:
1954
Serial number:
36-627
Stock number:
B600696
Feeds:
.003 To .125 I.P.R.
Swiveling:
Yes
Main motor:
30 HP
Table size:
36" 3-Jaw
Floor space:
10' L To R X 8'6" F To B
Table speed:
8.2 To 245 Rpm's
Fines regular:
.10 To .500 I.P.R.
Condition info:
Very Good
Machine height:
10'6"
Height under rail:
30"
Operators pendant:
Yes
Turret head position:
5
Side head travel in & out:
21"
Power clamping / elevation:
Yes
Side head travel up & down:
30"
Swing side head above table:
40"
Swing side head below table:
42"
Turret head travel left to right:
21"
Turret ram head turret travel up & down:
27"
Subcategory:
Boring mills
Subcategory 2:
Vertical turret lathe

Description

Table Size 36" 3-Jaw
Swing Side Head Above Table 40"
Swing Side Head Below Table 42"
Height Under Rail 30"
Table Speed 8.2 To 245 Rpm's
Feeds .003 To .125 I.P.R.
Fines Regular .10 To .500 I.P.R.
Main Motor 30 HP
Turret Head Travel Left To Right 21"
Turret Ram Head Turret Travel Up & Down 27"
Turret Head Position 5
Side Head Travel In & Out 21"
Side Head Travel Up & Down 30"
Floor Space 10' L To R X 8'6" F To B
Machine Height 10'6"
Operators Pendant Yes
Power Clamping / Elevation Yes
Swiveling Yes
Note: Machine Will Be Cleaned, Painted & Cycled.
Condition Very Good
