Location:
York, PA
Price:
$14,500 USD
Manufacturer:
BLISS
Model:
CH45

Specifications

Condition:
used
Year:
1973
Stock number:
15037
Size:
045 TON

Description

45 TON BLISS OBI PUNCH PRESS
PRICE: Loaded on Truck, Our Warehouse, York, PA ………… $14,500.00
Stock # 15037
Serial # H65056/HP49716
New 1973
Model: CH45
Bed Size: 29-1/2" x 18"
Ram Face: 20" x 14-1/4"
Center of Ram Back to Frame: 9-1/2"
14" Clear Back Thru Press Frame
2" Stroke
3" Adjustment
11-1/2" Shut Height
100 to 300 SPM
(2) 1-7/8" Diameter Strain Bars
Dual Palm Buttons
Press Controls for: Inch/Single Stroke/Continuous Run, Bar/Run,
Bumper On-Off, Recock On-Off, Speed Control Slower-Faster,
Hand or Foot (No Foot Pedal)
Red Lion Instrument Digital Display
Trabon Auto Lube System
Air Clutch & Brake
Air Counterbalance
6" Peterson Roll Feed, Model DRF63HS
29-1/2" x 18" x 3" Bolster Plate
OBI Base to Incline Press
7-1/2 HP Sterling VS Drive, 3/60/220-440
Overall Dimensions: 67" F-B x 62" L-R x 113" H
Approx. Weight: 8,000 Lbs.
