Location:
Navasota, TX
Model:
670
Weight:
11,250 Lbs.

Specifications

Condition:
used
Stock number:
G802537
Main motor:
7-1/2 Hp.
Table size:
17-3/4" X 59-1/2"
Cross travel:
17-3/4'
Longitudinal:
59-1/2'
Machine depth:
88-1/2"
Machine width:
217"
Condition info:
Very Good To Excellent
Machine weight:
11,250 Lbs.
Coolant with tank:
Yes
Magnetic chuck size:
16" X 48"
Incremental down feed:
Yes
Rapid traverse up & down:
Yes
Hydraulic dresser above wheel:
Yes
Vertical movement of wheel head:
19"
Grinding wheel speeds low / high:
1,750 To 2,100 Rpm's
Electromatic neutrofier for chuck:
Yes
Standard size grinding wheel low speed:
14"X 1-1/2" X 5"
Vertical working height with 14" wheel:
18"
Subcategory:
Grinders

Description

Table Size 17-3/4" X 59-1/2"
Magnetic Chuck Size 16" X 48"
Longitudinal 59-1/2'
Cross Travel 17-3/4'
Vertical Movement Of Wheel Head 19"
Vertical Working Height With 14" Wheel 18"
Standard Size Grinding Wheel Low Speed 14"X 1-1/2" X 5"
Grinding Wheel Speeds Low / High 1,750 To 2,100 Rpm's
Main Motor 7-1/2 Hp.
Machine Weight 11,250 Lbs.
Machine Width 217"
Machine Depth 88-1/2"
Electromatic Neutrofier For Chuck Yes
Rapid Traverse Up & Down Yes
Hydraulic Dresser Above Wheel Yes
Incremental Down Feed Yes
Coolant With Tank Yes
Note: Machine Will Be Cleaned, Painted And
Cycled. Machine Is Coming Out Of Nevada Power.
Condition Very Good To Excellent
