Location:
Lincolnshire, IL
Weight:
5,071 Lbs/2300 kg

Specifications

Condition:
used
Year:
2002
Stock number:
38126
Range:
0.3937"/10mm
Accuracy:
0.00003937"/0.001mm
Main power:
220VAC/60Hz
Cable-cross:
25mm2
Center drive:
5.0 HP/3.8kW
Working noise:
Approximately 78dB(A)
Control voltage:
V 230/50+24=
Ap 1 - idle operation:
Approximately 75dB(A)
Air connected - minimum:
6 Bar
Wheel diameter - maximum:
27.559"/700mm
Weight without accessories:
5,071 Lbs/2300 kg
Wheel ring width - maximum:
7.874"/200mm
Work piece height - maximum:
3.937"/100mm
Top and bottom wheels - each:
12.7 HP/9.5kW
Connected load/power requirement:
23kW/80A
Top wheel - continuously variable:
0 - 200 RPM
Bottom wheel - continuously variable:
0 - 200 RPM
Center drive - continuously variable:
0 - 100 RPM
Machine dimensions without coolant system:
86.6"L x 76"W x 105"H
Operating pressure adjustment - continuously variable:
0-1300 daN (Pneumatic)
Subcategory:
Lapping machines

Description

Serial No. 02.06.909 New - 2002
SPECIFICATIONS:
Working Range
Speeds
Drive Power
Electrical Equipment
Equipment w/DIN 57 113/VDE Completely Installed
Operating Pressure
Digital Measuring Instrument
Workplace-Based Noise Emission Value
EQUIPPED WITH:
Siemens Simatic Panel PC Controller
Loading and Unloading Tables
20" Inspection Straightedge with (2) Dial Gauges
*Preliminary Specifications Subject to Verification.
