WEEKE BP-12 CNC MACHINING CENTER
Location:
Spain
Price:
$24,343 USD
Model:
BP-12

Specifications

Condition:
used
Recnum:
BP-012208
Comments:
WEEKE "BP 12" a Great Starter or Dedicated Machining-Center!
Machtype:
CNC MACHINING CENTER (W/ATC)
Condition info:
(3-6) Good condition [5]
Current status:
Active
Elect./voltage:
400 V, 50/60 Cy, 3 Ph.
Appr. repl. cost:
84000

Description

WEEKE BP-12 CNC MACHINING CENTER (W/ATC);

-- Specifications:Work area cap. "X" axis 2,750 mm (108"), "Y" axis 900 mm (35.4"), "Z" axis stroke 140 mm (5.5").

-- Positioning Speed:"X" axis is 213 FPM (65 MPM), "Y" axis 164 FPM (50 MPM), "Z" axis 49 FPM (15 MPM)The head travels on THK linear motion guides on all axes.

-- Work area:(8) Moveable support rails w/side mounted raise-and-lower panel feeding rails, (8) pneumatic backstops, (2) movable pneumatic side stopsDual central zero-stop create (2) working zones & allow for (4) work pieces at a time.

-- Boring unit (16) independent vertical spindles, (10) in "X" axis & (6) in "Y" axis with (1) shared spindle, (2) special separate spindles for up to 35 mm dia.(4) Horizontal spindles with (1+1) in "X" & (1+1) in "Y" axis (1) 2 HP (1.5 kW) NC controlled 0° - 90° "X/Y" grooving saw with 100 - 150 mm dia. blade capacity

-- Machining:(1) 10 HP (7.5 kW) electro-spindle with "SK-30" adaptor, programmable from 9,000 - 18,000 RPM with constant torque from 12,000 RPM, RH or LH rotation;(1) 6-Tool ATC magazine located at the RH side of worktable

-- Operator & Machine Control:WEEKE Windows based 486/66 MHz controller: NUM PLC (programmable logic control) for (3) axes; linear, circular & helical interpolation.14" color graphic monitor, industrial keyboard for data entry, 3-1/2" floppy disk drive, 170 MB hard drive, 32-bit processor.EtherNET interface for possible LAN connection to office PC, RS-232 serial interface for simple PC connection; all mounted in separate free-standing control cabinet.

-- Complete with:(1) 100 m³/Hr BECKER Vacuum pump

-- Actual Model is WEEKE BP-12Note: EX-FACTORY’s Logistic Department is experienced and setup to provide “Full Service Logistic� from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.
