Top Seller
CLAUSING DRILLS in Dodge Center,
Location:
Dodge Center, MN
Price:
$10,765 USD
Manufacturer:
Clausing
Model:
20-502 2 SPINDLE
Capacity:
1-1/4" DIAMETER

Specifications

Condition:
new
Stock number:
061885
Rpm:
150-2000
Swing:
20"
Capacity:
1-1/4" DIAMETER
Table size:
25.5" X 45.5"
Drill heads:
2 (PART # 2286-300)
Spindle nose:
MT #3
2-speed motor:
220 VOLT, 3 PHASE
Column length:
43"
Spindle travel:
6-1/2"
Spindle to table:
25.437"
Quill return spring:
40 LBS
Subcategory:
Drills
Subcategory 2:
Multiple spindle

Description

CLAUSING (NEW) MODEL 2286-300 2 SPINDLE DRILL
PRESS
COMPONENTS:
DRILL HEADS ............. 2 (PART # 2286-300)
TABLE FOR 2 DRILL HEADS . 1 (PART # 20-502)
CAPACITY ................ 1-1/4" DIAMETER
SWING ................... 20"
TABLE SIZE .............. 25.5" X 45.5"
SPINDLE NOSE ............ MT #3
SPINDLE TRAVEL .......... 6-1/2"
COLUMN - GROUND STEEL ... 4" DIA, 3/8" WALL
QUILL - GROUND STEEL .... 2-1/2" DIAMETER
QUILL RETURN SPRING ..... 40 LBS
COLUMN TO SPINDLE CTR ... 10"
COL. BRACKET TO SPINDLE . 9.25"
SPINDLE TO TABLE ........ 25.437"
MIN CENTER TO CENTER .... 20"
COLUMN LENGTH ........... 43"
RPM ..................... 150-2000
2-SPEED MOTOR ........... 220 VOLT, 3 PHASE
