KENT GRINDERS in Dodge Center,
Location:
Dodge Center, MN
Model:
SGS-2060AHD

Specifications

Condition:
new
Stock number:
060166
T slot:
3 X 9/16"
Table size:
19 2/3" X 59 1/4"
Table speed:
16-80 FT/MIN
Wheel speed:
1750 RPM
Spindle motor:
10 HP
Fagor & others:
$ POR
Grinding wheel:
16" X 2" X 5"
Cross feed travel:
22"
Extra wheel flange:
$ POR
Msd-7 control unit:
$ POR
Longitudinal travel:
63"
Vertical graduation:
0.0001"
Vertical revolution:
0.0200"
Dro installation charge:
$ POR
Subcategory:
Surface
Subcategory 2:
Grinders

Description

(NEW) KENT MODEL SGS-2060AHD SURFACE GRINDER
LONGITUDINAL TRAVEL ....... 63"
CROSS FEED TRAVEL ......... 22"
TABLE SIZE ................ 19 2/3" X 59 1/4"
T SLOT .................... 3 X 9/16"
WHEEL SPEED ............... 1750 RPM
SPINDLE MOTOR ............. 10 HP
GRINDING WHEEL ............ 16" X 2" X 5"
VERTICAL GRADUATION ....... 0.0001"
VERTICAL REVOLUTION ....... 0.0200"
SPINDLE CENTER TO TABLE ... 23-5/8"
TABLE SPEED ............... 16-80 FT/MIN
AUTO INCREMENTAL DOWNFEED
VARIABLE ( 10 STEPS 0.0002" TO 0.0020" )
3 AXIS AUTOMATIC MOVEMENT,PRECISION TEFLON
WAYS, DOUBLE-VEE COLUMN CROSS TRAVERSE,
HYDRAULIC TABLE & ELECTRONIC CROSSFEED,
AUTOMATIC LUBRICATOR & RAPID ELEVATION,
PRICE ALSO INCLUDES
MAGNETIC SEPARATOR &PAPER FILTER COOLANT UNIT
20" X 60" ELECTRO-MAGNETIC CHUCK & CONTROL
OVERHEAD PARALLEL DRESSER
ON SITE START UP INSTALLATION OF MACHINE
STANDARD ACCESSORIES
1 PC. WHEEL BALANCING BASE
1 PC. GRINDING WHEEL
1 PC. DIAMOND TABLE DRESSER
1 PC. WHEEL BALANCING ARBOR
1 PC. WHEEL FLANGE
1 SET TOOL BOX WITH TOOLS
OPTIONAL ACCESSORIES
WALKER 20" X 60" INTERLOC LOW PROFILE
ELECTRO-MAGNETIC CHUCK WITH
MSD-7 CONTROL UNIT ............. $ POR
STUHR STATIC WHEEL BALANCER .... $ POR
EXTRA WHEEL FLANGE ............. $ POR
DRO SYSTEMS (MITUTOYO,SONY,
FAGOR & OTHERS ................. $ POR
DRO INSTALLATION CHARGE ........ $ POR
EVERYTHING F.O.B. CALIFORNIA
