Top Seller
EDWARDS IRONWORKERS in Dodge Center,
Location:
Dodge Center, MN
Price:
$7,796 USD
Manufacturer:
Edwards
Model:
JAWS IV 40 TON
Capacity:
40 TON

Specifications

Condition:
new
Stock number:
061623
Amp:
14 AMP
Rpm:
1725 RPM
Volts:
208/240 VOLT
Cylinder:
8-1/2" - 2-1/2" RAM
Reservoir:
7 GALLONS
Cycle time:
2 SECONDS
Open height:
8"
Shut height:
7"
Work height:
41-1/2"
Maximum size:
3" X 3" X 1/4"
Throat depth:
7"
Work height 2:
33-1/2"
Work height 3:
52-1/2"
Electric motor:
5 HP, 3 PHASE
Rated capacity:
40 TON
Valve pressure:
3000 PSI
Electric motor options:
PRICE ON REQUEST
Subcategory:
Ironworkers

Description

EDWARDS (NEW) MODEL JAWS IV 40 TON IRONWORKER
4 STATIONS
PUNCHING
MAXIMUM CAPACITY .... 1" DIA IN 1/2" PLATE
WORK HEIGHT ......... 41-1/2"
FLAT BAR SHEARING
MAXIMUM THICKNESS ... 3/8" X 10"
WORK HEIGHT ......... 33-1/2"
ANGLE SHEAR
MAXIMUM SIZE ........ 3" X 3" X 1/4"
WORK HEIGHT ......... 52-1/2"
GENERAL SPECIFICATIONS:
RATED CAPACITY ...... 40 TON
THROAT DEPTH ........ 7"
OPEN HEIGHT ......... 8"
SHUT HEIGHT ......... 7"
CYCLE TIME .......... 2 SECONDS
ELECTRIC MOTOR ...... 5 HP, 3 PHASE
VOLTS ............... 208/240 VOLT
RPM ................. 1725 RPM
AMP ................. 14 AMP
HYDRAULIC PUMP SIZE . 3-1/2 GPM - 1 STAGE
VALVE PRESSURE ...... 3000 PSI
RESERVOIR ........... 7 GALLONS
CYLINDER ............ 8-1/2" - 2-1/2" RAM
STANDARD FEATURES:
ELECTRIC STROKE CONTROL
ELECTRIC FOOT PEDAL
PEDESTAL DIE TABLE
AUXILIARY M12 POWER PORT
ELECTRIC MOTOR OPTIONS ..... PRICE ON REQUEST
5 HP, 3 PH, 440/480 VOLT OR 575 VOLT, 7 AMP
5 HP, 1 PH, 208/240 VOLT, 1725 RPM, 26 AMP
OPTIONAL TOOLS/ACCESSORIES . PRICE ON REQUEST
HYDRAULIC ACCESSORY PACK ............... POR
ACCESSORY LIGHT ........................ POR
AUTO CUT ............................... POR
ANGLE NOTCHER 3" X 3" X 1/4" ........... POR
BRAKE W/4-WAY DIE 1/16" 1/8" 3/16" 1/4" POR
COPER/NOTCHER .......................... POR
MULTI SHEAR ............................ POR
PIPE NOTCHER HOUSING ................... POR
QUICK CHANGE PUNCH COUPLING ............ POR
ROD SHEAR & HOUSING
1/4", 3/8", 1/2", 5/8", 3/4", 1" ...... POR
