ACCORD LATHES in Dodge Center,
Location:
Dodge Center, MN
Price:
$9,500 USD
Manufacturer:
Accord lathes
Model:
KGL-1640
Spindle Bore:
2"
Distance between Centers:
40"

Specifications

Condition:
new
Stock number:
061835
Bed width:
10"
Cross feed:
0.001-0.0335"
Quill taper:
MT #4
Quill travel:
4 3/4"
Spindle bore:
2"
Spindle nose:
D1-6
Swing in gap:
23-1/4"
Center height:
8"
Length of gap:
9"
Spindle taper:
MT #6
5c collet sets:
ROUND, SQ HEX .... POR
Quill diameter:
2"
Swing over bed:
16"
Leadscrew pitch:
4 TPI
Inch threads (45):
2-72 TPI
Maximum tool size:
3/4" X 3/4"
Optional equipment:
PRICE ON REQUEST
Metric threads (39):
0.2-14 MM
Spindle speeds (16):
45-1800 RPM
Longitudinal feed ipr:
0.002"-0.067"
Swing over cross side:
10"
Maximum compound travel:
5-1/2"
Distance between centers:
40"
Subcategory:
Engine

Description

ACCORD (NEW) MODEL KGL-1640 ENGINE LATHE
CAPACITY:
- SWING OVER BED ................ 16"
- DISTANCE BETWEEN CENTERS ...... 40"
- SWING OVER CROSS SIDE ......... 10"
- SWING IN GAP .................. 23-1/4"
- LENGTH OF GAP ................. 9"
- CENTER HEIGHT ................. 8"
- BED WIDTH ..................... 10"
- MAXIMUM TOOL SIZE ............. 3/4" X 3/4"
- MAXIMUM CROSS SLIDE TRAVEL .... 6-7/8"
- MAXIMUM COMPOUND TRAVEL ....... 5-1/2"
HEADSTOCK:
- SPINDLE BORE .................. 2"
- SPINDLE NOSE .................. D1-6
- SPINDLE TAPER ................. MT #6
- SPINDLE SPEEDS (16) ........... 45-1800 RPM
FEEDS & THREADS:
- LEADSCREW PITCH ............... 4 TPI
- INCH THREADS (45) ............. 2-72 TPI
- METRIC THREADS (39) ........... 0.2-14 MM
- CROSS FEED .................. 0.001-0.0335"
- LONGITUDINAL FEED IPR ....... 0.002"-0.067"
TAIL STOCK:
- QUILL TRAVEL .................. 4 3/4"
- QUILL DIAMETER ................ 2"
- QUILL TAPER ................... MT #4
MOTOR:
- MAIN MOTOR SINGLE SPEED .. 6 HP, 220V, 3 PH
FEATURES:
- TOTALLY ENCLOSED QUICK CHANGE GEAR BOX
- FULL LENGTH FOOT BRAKE
- COOLANT SYSTEM
- HIGH-TENSILE CAST IRON BED
- HARDENED AND GROUND WAYS
- PRECISION CLASS 30212-30210 MAIN SPINDLE
BEARINGS
- PERMANENTLY FILTERED HEADSTOCK OIL BATH
STANDARD EQUIPMENT:
- 2-AXIS DIGITAL READOUT SYSTEM
- TAPER TURNING ATTACHMENT
- 3-JAW CHUCK
- 4-JAW CHUCK
- FACE PLATE
- 4-WAY TOOL POST
- THREAD DIAL
- HALOGEN WORK LAMP
- REAR SPLASH GUARD
- STEADY REST
- FOLLOW REST
- REMOVABLE GAP
- DEAD CENTERS AND SLEEVE
- OPERATION AND PARTS MANUAL
OPTIONAL EQUIPMENT ......... PRICE ON REQUEST
- 5C COLLET CLOSER ................. POR
- 5C COLLET SETS: ROUND, SQ HEX .... POR
- MICROMETER CARRIAGE STOP ......... POR
- JACOBS KEYED DRILL CHUCKS ........ POR
- QUICK CHANGE TOOL SYSTEM ......... POR
- LIVE CENTERS ..................... POR
