Location:
Navasota, TX
Manufacturer:
Mazak lathes
Model:
18
Spindle Nose:
L-1

Specifications

Condition:
used
Stock number:
L3000170
Feeds:
.0030 To .0424
Weight:
5,000 Lbs.
Chuck size:
12" 3-Jaw
Main motor:
7-1/2 HP
Tail stock:
2 Speed
Coolant pan:
Yes
Floor space:
41" Wide X 84" Long
Thread dial:
Yes
Spindle hole:
3"
Spindle nose:
L-1
Condition info:
Good
Machine height:
60"
Spindle speeds:
25 To 1,500 Rpm's
Center distance:
36"
Tail stock taper:
# 4 Morse
Taper attachment:
Yes
Threads inch (40):
4 To 56 TPI
Module threads (20):
.5 To 7 MM
Swing over bed ways:
18"
Threads metric (20):
.5 To 7
Swing over cross slide:
8"
Hardened and ground way:
Yes
Tail stock quill travel:
8"
Diametrical threads (19):
4 To 28 TPI
Tail stock quill diameter:
3-1/2"
Subcategory:
Engine

Description

Swing Over Bed Ways 18"
Swing Over Cross Slide 8"
Center Distance 36"
Spindle Hole 3"
Spindle Speeds 25 To 1,500 Rpm's
Spindle Nose L-1
Chuck Size 12" 3-Jaw
Feeds .0030 To .0424
Threads Inch (40) 4 To 56 TPI
Threads Metric (20) .5 To 7
Diametrical Threads (19) 4 To 28 TPI
Module Threads (20) .5 To 7 MM
Tail Stock Quill Diameter 3-1/2"
Tail Stock Quill Travel 8"
Tail Stock Taper # 4 Morse
Tail Stock 2 Speed
Steady Rest
Main Motor 7-1/2 HP
Weight 5,000 Lbs.
Floor Space 41" Wide X 84" Long
Machine Height 60"
Coolant Pan Yes
Taper Attachment Yes
Thread Dial Yes
Hardened And Ground Way Yes
Note: Machine Has Been Cleaned, Painted And
Cycled.
Condition Good
