2005 MAKOR MULTILEVEL 6 MULTI-LAYER

2005 MAKOR MULTILEVEL 6 MULTI-LAYER DRYING / FLASH-OFF OVEN [FO-010411] in United States

Location:
United States
Price:
$79,900 USD
Manufacturer:
MAKOR
Model:
MULTILEVEL 6

Specifications

Condition:
used
Year:
2005
Recnum:
FO-010411
Comments:
"Excellent" Condition machine at an "Excellent" price!
Machtype:
MULTI-LAYER DRYING / FLASH-OFF OVEN
Condition info:
(7-9) Excellent condition [7]
Current status:
Active
Elect./voltage:
380 V, 50 Cy, 3 Ph.
Appr. repl. cost:
150000

Description

MAKOR, model MULTILEVEL 6. Multi-Layer Drying / Flash-off Oven system with 6 belt conveyors.Machine Specifications:• Multi level accumulator enables in-line flash-off utilizing minimal floor space.• Six (6) belt type trays for product accumulation.• Work length of each tray accommodates a charge of 4500 mm (177�).• Heated enclosure provides an ideal flash-off environment for sprayed coating materials.• Intake and exhaust air fans provide channeled air flow movement for efficient operation.• Air intake section contains a heat exchanger (hot water; boiler not included) with automatic temperature adjustment to supply temperature controlled input air.Not Included:• In and out feed conveyor.• Hot water boiler.Working Dimensions:• Max. / Min piece length: 4,500 mm / 300 mm (177" / 11 3/4").• Max. / Min. piece width: 1,300 mm / 20 mm (51" / 3/4").• Max. / Min. piece thickness: 40 mm / 9 mm (1 1/2" / 3/8").Plates:• Dimensions: 5,500 mm x 1,450 mm (216" x 57").• Maximum weight per plate: 90 Kgs (198 Pounds).• Number of plates: 6Technical Specifications:• Overall dimensions (l x w x h): 6,850 x 4,250 x 2,630 mm (270" x167" x104").• Max speed: 8 MPM ( 26 FPM).• Total electrical power: 6.6 Kw.• Total Exhaust Capacity: 7000 M³/h (4100 CFM).• Heat exchanger operating with hot water supply from boiler (Boiler not included), capacity: Approx. 80,000 Kcal/h.OPTIONALLY WE QUOTE: COMPLETE REFURBISHING OF THE UNIT; PRICE: $ 18,000.00ACTUAL MODEL: MAKOR MULTILEVEL 6.Note: EX-FACTORY’s Logistic Department is experienced and setup to provide “Full Service Logistic� from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.
