Top Seller
CLAUSING KC12SA 12", KALAMAZOO 12"
Location:
McClellan Park, CA
Manufacturer:
Clausing saws
Model:
KC12SA
Motor:
5 Hp (3.75 kw), 230/460v 3ph*
Weight:
1,540 lbs (698 kg)

Specifications

Condition:
new
Stock number:
8176
Motor:
5 Hp (3.75 kw), 230/460v 3ph*
Round:
12.75" (325 mm)
Width:
75" (1905 mm)
Length:
32" (812 mm)
Coolant:
Recirculating
Bed height:
26" (660 mm)
Blade size:
1.25" x .042" x 12'-6" (32 x 1 x 3810mm)
Net weight:
1,540 lbs (698 kg)
Rectangular:
12.75" x 12.6" (325 x 320mm)
Band wheel dia:
16" (406mm)
Shipping weight:
1,760 lbs (798 kg)
Coolant capacity:
10 gallons (39 liters)
Height (head-up):
67" (1702 mm)
Height (head-down):
57" (1449 mm)
Bundle cutting width:
6.5" to 10" (165 to 254mm)
Hydraulic pump motor:
1 Hp (.75 kw)
Bundle cutting height:
2" to 8" (51 to 203mm)
Hydraulic oil capacity:
6.5 gallons (25 liters)
Blade speeds (variable speed):
95-395 fpm (30-120 m/min)

Description

Model: KC12SA
Motor: 5 Hp (3.75 kw), 230/460v 3ph*
Hydraulic Pump Motor: 1 Hp (.75 kw)
Hydraulic Oil Capacity: 6.5 gallons (25 liters)
Band Wheel Dia.: 16" (406mm)
Blade Speeds (Variable speed): 95-395 fpm (30-120 m/min)
Blade Size: 1.25" x .042" x 12'-6" (32 x 1 x 3810mm)
Coolant: Recirculating
Coolant Capacity: 10 gallons (39 liters)
CUTTING CAPACITY:
@ 90 Degrees:
Round: 12.75" (325 mm)
Rectangular: 12.75" x 12.6" (325 x 320mm)
7.9" x 14.2" (200 x 360mm)
**Bundle Cutting Width: 6.5" to 10" (165 to 254mm)
**Bundle Cutting Height: 2" to 8" (51 to 203mm)
Length: 32" (812 mm)
Width: 75" (1905 mm)
Height (head-down): 57" (1449 mm)
Height (head-up): 67" (1702 mm)
Bed Height: 26" (660 mm)
Net Weight: 1,540 lbs (698 kg)
Shipping Weight: 1,760 lbs (798 kg)
Other voltages optional.
FEATURES:
* 5 Hp 230/460v 3 ph drive motor
* Semi-automatic operation
* Infinitely variable blade speeds
* LED blade speed readout
* Vise clamps work piece both sides of blade
* Powered hydraulic down feed
* Automatic height setting feature
* Auto shutoff at end of cuts
* Blade breakage/stoppage switch
* 110v control circuit
* Overload protection
* Recirculating coolant system
* (1) general purpose bi-metal blade
* (1) gallon coolant
* Flushing hose for cleanup
* Operator's manual
TWO (2)-YEAR LIMITED WARRANTY!!
