Top Seller
JMT MS 2003 1/8" x
Location:
McClellan Park, CA
Manufacturer:
JMT
Model:
MS 2003
Capacity:
1/8"
Weight:
2,900 lbs

Specifications

Condition:
new
Stock number:
8103
Width:
53"
Height:
48"
Length:
95"
Table width:
15.75"
Table height:
33"
Cutting angle:
2 Degrees
Approx. weight:
2,900 lbs
Cutting length:
6'8"
Motor power 3ph:
3
Back gauge range:
22"
Cutting capacity:
1/8"
Strokes per minute:
35
Rake angle (per foot):
7/16"
Subcategory:
Shears
Subcategory 2:
Power shears

Description

Model: MS 2003
Cutting Capacity: 1/8"
Cutting Length: 6'8"
Cutting Angle: 2 Degrees
Rake Angle (per foot): 7/16"
Strokes per Minute: 35
Motor Power 3PH: 3
Back Gauge Range: 22"
Table Width: 15.75"
Table Height: 33"
Height: 48"
Width: 53"
Length: 95"
Approx. Weight: 2,900 lbs.
STANDARD EQUIPMENT:
* High-yield, heavy duty steel construction (St 44) and
stress-relieved frame
* Easy blade gap adjustment
* Manual back gauge
* Finger protect
* Portable foot control with emergency stop button
* Top blades with 2 sides, bottom blades with 2 sides
* World standard electrical/mechanical components
OPTIONAL EQUIPMENT:
* User-friendly CNC Touchscreen control unit (D-Touch 7)
* Ball screw motorized bag gauge
* Special back gauge
* Pneumatic thin sheet support system
* Sheet support device with conveyor belt and scrap
container
* Stacker + alignment cylinder
* Adjustable angle stop 0-180 degrees
* Additional support arms
* Special blades
* Hold down with rubber
* Special color
* Many options and customizations are available - please
contact us for details.
