2016 MEGA MNL 55m3 KD
Location:
Łódź, Poland
Price:
$27,062 USD
Manufacturer:
MEGA
Model:
MNL 55m3 KD

Specifications

Condition:
used
Year:
2016
Axles:
3
Volume:
53.6 l
Net weight:
6600 kg
Spare wheel:
yes
Axles; brand:
MEGA
Lifting axis:
yes
Load capacity:
33400 kg
Axles; tyre size:
385/65 22,5
Body; dimensions:
10.4 m × 2.47 m × 2.15 m
Axles; suspension:
air/air
Vehicle condition:
excellent
Axles; tyre condition:
100 %
Subcategory:
Semi-trailers
Subcategory 2:
Tipper semi-trailer

Description

- Total weight: 40.000kg
- Weight: 6.600kg
- Payload 33.400kg
- Focus on the saddle: 13.000kg
- Axle: 8 .000kg (9.000 kg Technical)
- Volume bumps: 55 m3
- Internal length: 10.370mm
- Internal width: 2.470mm
- Internal height: 2.092mm
- Total length: 11.800mm
- Overall width: 2.550mm
- Overall height: 3.580mm
I. Technical Description
Chassis
- Frame: made of high quality steel RUKKI (OPTIM 650)
- Chassis: 3 axles brands MEGA - DRUM.
- Coupling plate with a 2 inch king pin JOST
- Two dual-band support legs JOST with a capacity of 12 tonnes - each.
- Tubeless Tires 385/65 22.5 '' - 7szt. 6 pcs. + 1 pc. Spare wheel)
- Basket for 2 spare wheels
- Alloy Steel
- Dust-side entry in accordance with ECE
- Working platform (attached to the frame)
- Rear bumper with apron.
II. Body
- Case made of high quality aluminum profiles with increased resistance to abrasion - 30mm.
- The front wall oblique.
- Closing the rear flap - door.
- Panels welded from the inside over the entire length.
- Rubber Washers - aluminum welded into the ark - between the frame and the floor chest.
- Slides stabilizing the position of the gearbox on the frame
- A hydraulic cylinder: HYVA - fixing the upper.
- Balcony (work platform).
- Strengthen the trapezoidal side walls of the back of the case - 5mm.
- Brakes (drum) Two-wire Knorr company.
- Leveling valve to ramp COLAS
III. Suspension
- Pneumatic drive with constant height irrespective of the weight of the cargo.
- Two pneumatic connection sockets and the socket ABS / EBS placed on the front wall.
- Shock-2 pieces per axle.
- The first lifting axle valve automatically ILAS
- The system elektrycznyUkład 24-volt (compliant with ECE).
- Colour frame - graphite RAL 7016
- Color box - white
IV. Additional equipment
- Chocks under the wheels 2p.
- The key to the wheels with tommy bar.
- Plastic Toolbox
- 3M reflective tape on the sides of the trailer and on the flap.
- Water tank with tap and soap dish
- Attachment 2 spare wheels (galvanized).
- Hydraulic hose with screw-in reduction to the actuator 1 inch to ¾ inch.
- Stick to the curtain of the mounts on the frame.
- 2 pcs. Ekspandorów rubber.
- Two baffles cereal positioned symmetrically in klapo-door 50/50
- The cross - coupling beam boxes 3 pieces.
- Belts to fasten tarps 3 pieces.
