Top Seller
DAKE PRESSES in Dodge Center,
Location:
Dodge Center, MN
Manufacturer:
Dake presses
Model:
909215 FORCE 25DA
Capacity:
1.5 GAL

Specifications

Condition:
new
Stock number:
061943
Amp:
20
Rpm:
3,450 RPM
Voltage:
110 V 1PH
Horsepower:
1 HP
Ram travel:
10"
Oil capacity:
1.5 GAL
Rated capacity:
25 TON
Return ram speed:
19 IPM
Maximum ram to table:
44"
Minimum ram to table:
8"
Width between uprights:
28"
Ram speed-inches per minute:
10 IPM
Width between table channels:
7"
Subcategory:
Hydraulic

Description

DAKE (NEW) MODEL 909215 FORCE 25DA H-FRAME
HYDRAULIC POWERED PRESS
RATED CAPACITY ................... 25 TON
HORSEPOWER ....................... 1 HP
RPM .............................. 3,450 RPM
RAM TRAVEL ....................... 10"
RAM SPEED-INCHES PER MINUTE ...... 10 IPM
RETURN RAM SPEED ................. 19 IPM
OIL CAPACITY .................... 1.5 GAL
WIDTH BETWEEN UPRIGHTS ........... 28"
WIDTH BETWEEN TABLE CHANNELS ..... 7"
MINIMUM RAM TO TABLE ............. 8"
MAXIMUM RAM TO TABLE ............. 44"
VOLTAGE .......................... 110 V 1PH
AMP .............................. 20
FEATURES:
- MADE IN THE USA
- LEVER CONTROL RAM ADVANCE
- ONE HAND RAM POSITIONING
- 4-WAY VALVE WITH JOYSTICK CONTROL
- WELDED STEEL FRAME
- LOW OPERATING PRESSURES
- DOUBLE ACTING CYLINDER FOR RAM POSITIONING
- FAST, QUIET, DEPENDABLE
- SMOOTH EASY-TO-OPERATE PRESS
- HEAVY ADJUSTABLE TABLE CAN BE SET TO A
COMFORTABLE WORK HEIGHT
- MASSIVE TABLE PINS KEEP TABLE SECURELY IN
PLACE DURING PRESSING OPERATIONS
- PRESSURE PRESET AND LOCKED OUT AT FACTORY
FOR MAXIMUM PRESSING
- SAFETY RELIEF VALVE
- RAPID ADVANCE OF THE RAM TO THE WORK PIECE-
WHEN CONTACT IS MADE, THE MACHINE SHIFTS
INTO PRESSING MODE
- 1-YEAR WARRANTY
- COMPLETE OWNERS MANUAL
STANDARD EQUIPMENT:
- FRAME
- CYLINDER
- 2 FORGED STEEL TABLE PLATES
- PRESSURE GAUGE
- LIFTING CHAIN
