Location:
Lincolnwood, IL
Manufacturer:
Hannifin
Model:
S-35 84-12-4-1-
Capacity:
1820 PSI
Stroke:
12"

Specifications

Condition:
used
Stock number:
pp1275
Tonnage:
35 Ton
Table size:
12" x 84"
Dia. of ram:
5"
Ram speed up:
122 IPM
Cylinder bore:
7"
Hydraulic pump:
10 HP 3/60/460V
Overall height:
105"
Ram speed down:
60 IPM
Table to floor:
36"
Approximate weight:
5,000 lbs
Stroke of cylinder:
12"
C/l of ram to column:
10"
Max. distance table to ram:
22-1/2"
Operating pressure of rated capacity:
1820 PSI
Subcategory:
Straightening

Description

Equipped With:
Hannifin Foot Lever and Hand Levers. Dual Palm Dual Sensitive Pressure Control Permits Operator to Start, Restart or Retract the Ram at any point. 12" x 84" T-slotted Straightening Table. Adjustable Ram Guide. Large Dramatic Pressure Gauge.
