Location:
Elk Grove Village, IL
Manufacturer:
Hey
Model:
No. 3
Weight:
5,900 Lbs.

Specifications

Condition:
used
Year:
1981
Serial number:
2824-880
Stock number:
3270
(1 vise):
0.75"
Floor space:
96" x 42" x 72"H
Speed range:
80 - 1,720 RPM
Condition info:
Good
Weight, approx:
5,900 Lbs.
8 feed rates of:
0.001 to .018 IPR
Cutter spindles:
No. 40 NST
Max. work length:
27"
Rapid traverse rate:
250"/ Min.
Max diameter over bed:
21"
Max. diameter of work:
6.25"
Min. diameter of work:
0.25"
Min. work length (2 vises):
3.0"
Length of micrometer adj. to cutter:
2.0"
Subcategory:
Centering machines

Description

Equipped With:
(2) Pneumatic Workholding Vises, Auto. Work Cycle, Chip Conveyor, Coolant Pump, High Speed Feed Overdrive 1/2 HP (220/440V motor), 2 Spindle Head Drive 15 HP 220/440V Motors & Electrical Controls
