1996 HOLZMA HPL 22-32/16 REAR LOAD, AUTO. PANEL SAW [PK-011016] in United States

Location:
United States
Price:
$17,900 USD
Manufacturer:
Holzma
Model:
HPL 22-32/16

Specifications

Condition:
used
Year:
1996
Recnum:
PK-011016
Comments:
Huge Savings!!! Must move this 5" cutting height HOLZMA Rear Load Saw right away (02-2016)!
Machtype:
REAR LOAD, AUTO. PANEL SAW
Condition info:
(3-6) Good Condition [4]
Current status:
Active
Elect./voltage:
220 V, 60 Cy, 3 Ph.
Appr. repl. cost:
225000

Description

HOLZMA HPL-22/32/16 Rear Load panel Saw

-- Specifications: 126" (3,200 mm) Cutting length and between cutting line & program fence; 5.3" (135 mm) max. saw blade projection; 40 HP (30 kW) main & 3 HP (2.2 kW) scoring motor.

-- Variable saw carriage travel speed from 16 - 328 FPM (5 - 100 MPM), constant return of 328 FPM (100 MPM); main blade 500 mm dia. & scoring blade 200 mm diameter.

-- Electronically controlled overhead program fence, rack & pinion driven on both sides by AC Servo drive, forward speed from 0 - 230 FPM (0 - 70 MPM), return speed of 230 FPM (70 MPM); includes (7) clamps that open up to 5.3" / 135 mm.

-- Features: HOLZMA "CADMATIC" control with: 14" Color monitor (displays cutting dimensions & patterns in moving colored graphics), (500) cutting dimension memory, extended to 1 MB (99 times repeatable).

-- Data input by keyboard or (2) 3-1/2" floppy disk drives or RS-232 downloading from office PC, control panel w/CADMATIC housed in control cabinet mounted on double swiveling arm for ergonomic positioning by the operator.

-- Complete with: Combi-rollers rear machine table with profile rails, rollers spaced at 50 mm centers; front with (1) air flotation tables 110" x 26" (2,810 x 650 mm) & (3) air flotation tables 85" x 26" (2,160 x 650 mm).

-- Angular fence, side pressure device for crosscutting on pressure beam & (2) aligning devices on program fence.

-- Includes: Automatic scoring saw adjustment from the outside during operation, patented "Quick Saw Changing System" for main & scoring blade.

-- 7-Ton Automatic electro-hydraulic 4-column rear load Lift Table, max. panel size when loading from the rear is 150" x 63" (3,800 mm x 1,600 mm). Loading/unloading is possible from rear and/or LH side facing.

-- 26.7" (680 mm) Max stack height w/o a pit or risers & 34.6" (880 mm with pit or risers. Options Include: Powered in-feed conveyor with fork cut-outs.

-- Actual model is HOLZMA HPL 22-32/16.
