2008 KENTWOOD R 450X 3M

2008 KENTWOOD R 450X 3M DIP CHAIN GANG RIP SAW WITH MOVABLE BLADE [RG-011402] in United States

Location:
United States
Price:
$142,800 USD
Manufacturer:
KENTWOOD
Model:
R 450X 3M

Specifications

Condition:
used
Year:
2008
Recnum:
RG-011402
Comments:
Designed for HEAVY production volumes and with moving blade technology.
Machtype:
DIP CHAIN GANG RIP SAW WITH MOVABLE BLADE
Condition info:
(7-9) Excellent condition [7]
Current status:
Active
Elect./voltage:
460 V, 60 Cy, 3 Ph.
Appr. repl. cost:
335000

Description

KENTWOOD R 450X 3M HEAVY DUTY Selective Rip Saw with (3) Shifting Blades INCLUDING the Optimizing Infeed System:Designed for HEAVY production volumes and with moving blade technology. Features include a solid steel metal base and manually adjustable infeed fence; noise reducing lining to lower noise levels approximately 15db.

-- Capacities: 1" Min. - 18-1/4� max. rip width cap. x 3/4" min. to 4" max. cutting depth; 18-1/2� wide feed chain with max. pass max. width of 31-1/2".

-- Arbor driven by 60 HP motor at 3,500 RPM. With 9-3/4" min. and 15" max. saw blade diameter.

-- 3 HP feed motor with feed speeds to 264 FPM; feed chain runs on dual V-guide system providing best board control; with wear resistant chain dip cams and hardened chain pins

-- (3) Movable blades, servo driven for fast accurate positioning of the blade; blade sensors to prevent blade crashing; 3/4" min. to 10.3/4" max. distance between fixed and moving blades.

-- Fast setup of arbor; easy access with wide open hood and centrally arranged controls; low maintenance closed feed chain; automatic chain lubrication; maintenance-free saw arbor bearings.

-- Arbor motion detection to prevent the hood from opening while the blades are moving; (4) sets of anti kickback fingers; motorized pressure plate; (4) pressure rollers

-- Operator interface control for quick and easy cutlist setup for up to 99 different cutlists. Moving lasers provide quick reference to the blade's physical position. Optimization of boards with manual override capabilities via joystick control. Moving blade and arbor design along with a motorized pressure plate allow for quick setups.Standard Features include:

-- Cutting accuracy of 0.008" over 8' from a steel transport dip chain running on hardened steel guide rails for excellent board control and less friction.

-- Digital meter for easy reading of feed operating speed; amp meter for monitoring arbor motor load.

-- Inverter driven feed belt with adjustable speed potentiometer for speeds up to 265 FPM.

-- Five (5) independent top pressure rolls for cutting accuracy and control.

-- Control voltage-ready indicator lamps for both 110VAC and 24VDC; electronic amperage monitoring system with automatic speed reduction to reduce feed speed when required to avoid damage to arbor motor and saw blades.

-- Easily accessed V-belt driven saw arbor for reduced vibration and higher tolerances; five sets of anti kick back fingers.

-- Aluminum pressure shoe with holding brackets; hand wheel arbor height adjustment with position measuring scale; automatic oil pump with alarm notification relay.

-- Motion sensor device and locking safety hood with window along with panel light indication to indicate when it is safe to open the machine hood; limit switch on infeed to stop machine is case of oversized boards.

-- Automatic soft start and stop controls; emergency stop buttons on infeed and outfeed of machine; easy access to spindle and blades for maintenance and tooling c
