2009 GIBEN PRISMA 3000 FRONT

2009 GIBEN PRISMA 3000 FRONT LOAD, AUTOMATIC PANEL SAW [PH-012229] in United States

Location:
United States
Manufacturer:
GIBEN
Model:
PRISMA 3000

Specifications

Condition:
used
Year:
2009
Recnum:
PH-012229
Comments:
A very well maintained GIBEN PRISMA 3000...ready for Immediate delivery!
Machtype:
FRONT LOAD, AUTOMATIC PANEL SAW
Condition info:
(6-8) Very good condition [6]
Current status:
Active
Elect./voltage:
480 V, 60 Cy, 3 Ph.
Appr. repl. cost:
145000

Description

GIBEN PRISMA 3000 H115 SP FRONT LOAD, AUTOMATIC PANEL SAW

-- Specifications: 149.6" (3,800 mm) Overall cutting length, 161.4" (4,100 mm) pusher stroke; 4.5" (115 mm) max. saw blade projection, 25 HP (18.6 KW) main & 3.5 HP (2.6 KW) scoring motor.

-- Saw Carriage:Variable saw carriage speed from 0 - 558 FPM (0 - 170 MPM), return speed 558 FPM (170 MPM);Rack & pinion drive, driven by AC brushless Servo motors.

-- Pusher Fence:Electronically controlled overhead program fence with (6) floating pneumatic gripper clamps (open up to 4.6" / 117 mm).Forward speed of 3.2 - 196.8 FPM (1 - 60 MPM) & return speed of 196,8 FPM (60 MPM);Rack & pinion drive, driven by AC brushless Servo motors.

-- Operator & Machine Control:PC front end with Giben "G-Drive RT" + WINDOWS "NT" operating system with easy programming of very complex cutting patterns.15" Flat screen monitor displays REAL-TIME graphics of cutting dimensions & patterns, program cutting list, manual cuts, diagnostic & on-line help.Data input by adjustable key pad pendant, standard industrial keyboard & mouse & CD-ROM drive; direct downloading from office PC is possible.Giben "G-Drive RT" guarantees fully automatic management of cutting patterns by optimizing all machine movements (pressure beam, saw carriage and side aligner pusher positioning, etc.).The numerical control adjusts the optimum saw blade projection for the stack of panels being cut and sets the most appropriate cutting speed, in relation to the stack itself, and when necessary to the width of trim cut too.

-- Rear of machine:(9) Rear support rails with 80 mm dia roller modules; rear of machine enclosed for safety.

-- Front of machine:(2) Independent automatic side/crosscut aligning device with 2.75" - 87" (70 - 2,200 mm) stroke.90" (2,300 mm) Long crosscut fence (front-to-back); (4) Front mounted air floatation tables 20" x 78" (510 x 2,000 mm).

-- Complete with: "Quick Change" saw blade system; "REMOTE" electronic scoring adjustment.

-- Options Include: Label printer software, stand and printer.

-- Actual Model is GIBEN PRISMA 3000 H115 SP.
