Location:
Lakewood Township, NJ
Model:
YCM-42

Specifications

Condition:
used
Year:
1990

Description

SUPERMAX MODEL YCM-42 CNC VERTICAL MILLING MACHINE
WITH DELTA DYNAPATH 3-AXIS CONTROL
SERIAL NUMBER 005379          NEW 1990
GENERAL SPECIFICATIONS:
Table size 9" x 49"
Travels:
Longitudinal (X) 37"
Cross (Y) 16"
Vertical knee (Z) 16"
Ram 18"
Quill 5"
Turret rotation 360 Degrees
Spindle speeds (Variable) 60-4200 RPM
Spindle taper R-8
Quill feeds (3) .0017",.0032",.0053"
Overall dimesions 74"D x 105"L x 81"H
Weight (approx) 2,630 Lbs.
MOTOR SPECIFICATIONS:
3 HP 220/440 3/60 Main motor
Electrical controls
EQUIPPED WITH:
Delta Dynapath Conversation CNC Control
Power Draw Bar
Variable speed spinlde drive
Lube system
Way covers
