Location:
Contamine-sur-Arve, France
Price:
No price
Model:
MK603 HP/10

Specifications

Condition:
used
Year:
2004
Serial number:
460M240
Stock number:
8489
Height:
3,10 [m]
Tools type:
BT40 BIG PLUS
Floor space:
4,51 x 3,68 [m]
Quick feeds:
48 000 [mm/min]
Spindle power:
30 [kW]
Working hours:
4803 [h]
Machine weight:
13 000 [kg]
Pallets number:
2
Spindle speeds:
10 10 000 [Rpm]
Strokes x, y, z:
710 x 610 x 610 [mm]
Max. part height:
710 [mm]
Max. pallet weight:
500 [kg]
Max. part diameter:
680 [mm]
Pallets dimensions:
500 x 500 [mm]
Distance table / spindle axis:
85 to 695 [mm]
Subcategory:
Milling

Description

- CNC HEIDENHAIN iTNC530
- Supports RS232 and RJ45
- Electronic deported crank handle
- 4th continuous axis 360 000 positions
- Tool changer 60 positions with Random selection
- Spindle SKF
- Spindle fridge
- Lubricating tank with pumps
- Coolant through spindle 20 bars, 25 l/min
- Cabin and shower head coolant
- Chip conveyor
- Hydraulic part clamping 200 bars
- HEIDENHAIN TS640 infrared workpiece probe
- Status lamp
- Podium
