GIARDINA COMPLETE UV ROLL COAT

GIARDINA COMPLETE UV ROLL COAT SYS "UV" ROLL COAT FINISH LINE [FS-010589] in Italy

Location:
Italy
Manufacturer:
GIARDINA
Model:
COMPLETE UV ROLL COAT SYS

Specifications

Condition:
used
Recnum:
FS-010589
Comments:
Great UV roll coat line entirely refurbished at half the price of a new one, with full factory guarentee
Machtype:
"UV" ROLL COAT FINISH LINE
Condition info:
(9-10) Rebuilt w/Warranty [9]
Current status:
Active
Appr. repl. cost:
1.5e+006

Description

GIARDINA, 28 Position Roll Coater Line for Water Based Stain and 100% Solid UV filler, Base-coat/Sealer, Clear and Pigmented Top Coats.All the different machines of the line are fully refurbished and are offered with 6 months factory guarantee.Line Positions:1 GIARDINA, model BT-2500; Belt conveyor, 2.500 mm.2 Veneer Sander Cross-belt/Pad/Pad/Pad (NOT INCLUDED).3 GIARDINA, model G 95-20S; Panel cleaner.4 GIARDINA, model BT-2500; Roller conveyor, 2.500 mm.5 GIARDINA, model G 94-01; Roller coater for stain.Equipped with new relined sponge roll.6 GIARDINA, model BT-2000; Roller conveyor, 2.000 mm.7 GIARDINA, model G 94-01; Roller coater for stain.Equipped with new relined sponge roll.8 GIARDINA, model G30s3; Stain wiping machine with 3 distribution brushes.9 GIARDINA, model GPJET-10; Jet air stain drying tunnel.10 GIARDINA, model G94-09; Light filler machine.11 GIARDINA, model GST-UV 1400/1; UV bi-stage tunnel - 1 lamp 80 watt/cm².12 GIARDINA, model G94-08; Filler machine.13 GIARDINA, model GST-UV 1400/3; UV drying tunnel - 2 lamps 80 watt/cm² + 1 lamp 120 watt/cm².14 GIARDINA, model BT-2000; Roller conveyor, 2.000 mm.15 Veneer/Sealer Sander Pad/Pad (NOT INCLUDED).16 GIARDINA, model G9531-S3; Denibbing machine with 3 straight brushes.17 GIARDINA, model G 95-20S; Panel cleaner.18 GIARDINA, model BT-2000; Roller conveyor, 2.000 mm.19 GIARDINA, model G 94-05; Roller coater.20 GIARDINA, model GST-UV 1400/2; Bi-stage UV dryer - 2 lamps 80 watt/ cm².21 GIARDINA, model G 94-05; Roller coater.22 GIARDINA, model GST-UV 1400/2; Bi-stage UV dryer - 2 lamps 80 watt/ cm².23 GIARDINA, model G 94-05; Roller coater.Additional separate OPTI-ROLLER24 GIARDINA, model GST-UV 1400/2; Bi-stage UV dryer - 2 lamps 80 watt/ cm².25 GIARDINA, model BT-2000; Roller conveyor, 2.000 mm.26 GIARDINA, model G 94-05; Roller coater.Additional separate OPTI-ROLLER27 GIARDINA, model G 94-05; Roller coater.28 GIARDINA, model BT-2000; Roller conveyor, 2.000 mm.Covered by a Lexan hood.29 GIARDINA, model GST-UV 1400/4; Final UV drying tunnel - 3 lamps 80 watt/ cm² + 1 lamp 120 watt/ cm².30 GIARDINA, model BT-2000; Roller conveyor, 2.000 mm.NB. The Wide-Belt veneer/sealer sanders (Position 2 and 15) are not included in this line, and can be offered seperately. Full detailed offer upon request from Product Manager.Note: EX-FACTORY’s Logistic Department is experienced and setup to provide “Full Service Logistics� from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.�
