Horizontal Slant Bed Lathe CNC Turning Machining Parts Mini CNC Lathe Machine for Turning Metal 4 axis Flat Bed Lathe in Foshan, Guangdong, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Max. length of workpiece (mm)
- 230
- Structure
- Slant Bed Lathe
- Machining capacity
- Light Duty
- Max. weight of workpiece(kg)
- /
- Width of bed (mm)
- 25 mm
- Spindle motor power(kw)
- 3KW / 3.7KW
- No. of spindles
- Single
- Number of axes
- 3
- Travel (x axis)(mm)
- 600 mm
- Travel (z axis)(mm)
- 230 mm
- Positioning accuracy (mm)
- ±0.01
- Repeatability (x/y/z) (mm)
- 0.005
- Place of origin
- Guangdong China
- Dimension(l*w*h)
- Estimated 1750*1400*1800mm
- Voltage
- 380V
- Cnc control system
- Self Developed Control System
- Tool post stations
- 8 6 5
- Weight (kg)
- 1800
- Key selling points
- Cost Effective / Advanced Tech Stable System Durable
- Machinery test report
- Provided
- Video outgoing-inspection
- Provided
- Automatic grade
- Automatic CNC Lathe Machine
- Application
- Hardware Accessories and Hard Plastic Processing
- Cnc or not
- CNC
- Patents
- Self Developed Control System & Anti Deformation Base
- Oem service
- Customized Color / Logo Configurations Acceptable
- Power requirement
- 380V / 7.3KW 50Hz or 60Hz
- After warranty service
- Video Technical Support / Online Spare Parts
- Main features
- High Efficiency / Accuracy Stability ; Stable System & Durable
- Toolpost brand
- Non turret for this model
- Warranty of core components
- 1 Year
- Applicable industries
- Manufacturing Plant Machinery Hardware Products Accessories Processing Automotive Parts General Equipment Home Decoration Building Materials Appliance 3C (Computers/Communications/Consumer Electronics)
- Core components
- Bearing motor Pump Engine Spindle/Control System/Lead screw/Guide rail
- Max. turned length (mm)
- 230
- Max. spindle speed (r.p.m)
- 4000 r.p.m
- Spindle bore(mm)
- 35
- Spindle bore
- 35mm
- Max. swing diameter (mm)
- 250
- Category
- CNC Lathes in China
- Subcategory
- Lathe
- Subcategory 2
- Industrial machinery
- Subcategory 3
- Machine tool equipment
- Listing ID
- 103014718
Description
Recommend Products
Find more
$6,900 USD
