TAP C LL in Karlstein am Main, Bavaria, Germany
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Stock number
- 49-200975-028
- Product range
- Safety cabinets
- Product category
- Type 90 - flammable liquids
- Line
- TAP
- Execution
- C
- Size
- LL
- Storage type
- Active storage
- Function
- Filling
- Earthing connection
- Yes
- Ventilation connection
- Yes
- Tüv-süd certificate no.
- Z1A 012906 0520
- Tüv-süd certificate type
- GS
- Tüv-süd high quality certificate
- Z2 012906 0513
- Din en 14470-1
- Yes
- Din en 16121/16122
- Yes
- Outside wide
- 894 mm
- External depth
- 747 mm
- External height
- 2045 mm
- Max. load capacity per storage area
- 75 kg
- Max. payload
- 225 kg
- Max. total weight
- 740 kg
- Max. volume individual containers
- 30 L
- Collecting volume
- 33 L
- Weight (product)
- 500 kg
- Potential-free contact
- Yes
- Cupboard cladding material
- sheet steel
- Cabinet color
- electrically dissipative gray
- Interior cladding material
- sheet steel
- Interior paneling color
- electrically dissipative gray
- Socket
- classic
- Plinth height
- 89 mm
- Base color
- RAL 7015
- Number of doors
- 2
- Type of doors
- Hinged door
- Door panel material
- sheet steel
- Door color
- electrically dissipative blue
- Door operation
- One-handed
- Door technology
- classic
- Door handle
- Bow handle matt nickel
- Lock
- Cylinder lock
- Locking
- open
- Locking points
- 1-point
- Interior material
- sheet steel
- Interior color
- electrically dissipative gray
- Bottom drip tray
- firmly
- Warehouse floor
- Yes
- Storage levels (le)
- 3
- Storage areas (lb)
- 3
- Setting height
- 341 mm
- Load adapter
- Yes
- Monitoring exhaust air
- Yes
- Subcategory
- Safety cabinets from
- Listing ID
- 103132248
Description
The TAP line type 90 from DÜPERTHAL is specially designed for removing media from canisters and small drums. This enables flexible work processes and a more efficient organization of the internal value chain. This effectively leads to the release of resources that can be used actively and in a results-oriented manner for research.
Technical ventilationObject extraction during filling as well as aeration and ventilation at every cabinet level.
SafetySafe removal of media from canisters and drums into smaller containers in accordance with TRGS 509 (active storage).
Occupational safetyConductive powder coating as standard and universal earthing system in accordance with TRGS 727.
