CNC Turning Lathe Machine Price and Specification Ck6140 Small Lathe in Jiangsu, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Processing accessory
- Chuck CNC Lathe
- Guide rail
- Horizontal Guide Rail
- Tool holder
- Single-tool Holder CNC Lathe
- Power source
- Hydraulic Pressure
- Controlling mode
- CNC
- Automatic grade
- Semiautomatic
- Setting mode
- Table
- Precision
- High Precision
- Certification
- GS, CE, ISO 9001, SGS
- Transport package
- Wooden Box
- Specification
- 290X11X120 cm
- Production capacity
- 200sets
- Category
- CNC Lathes in China
- Subcategory
- Lathe
- Subcategory 2
- Machine tools
- Subcategory 3
- Manufacturing & processing machinery
- Listing ID
- 103180663
Description
C6250HA
SERIES HORIZONTAL LATHE
PRODUCT FEATURES
*THE SURFACE OF THE BEDWAYS IS SUPERSONIC FREQUENCY HARDENED.
*GEARS PRECISELY GROUND TO REDUCE NOISE.
*SPINDLE SYSTEM IS OF HIGH RIGIDITY AND PRECISION.
*RAPID FEED STRUCTRUE IS AVAILABLE ON APRON.
Model
C6250HA
CAPACITY
Max.swing over bed
500mm
Max.swing over cross slide
330mm
Max.swing over gap
660mm
Effective length of gap
200mm
Center Distance
1500mm
Bed Width
360mm
HEADSTOCK
Spindle hole
82mm
Spindle nose
ISO-C8
Spindle taper
MT8
Spindle speed(Number)
(9steps)40-1300rpm
FEEDS
Longitudinal feeds range
0.0832-4.66mm/r
Cross feeds range
0.048-2.69mm/r
Metric threads range
19kinds 0.25-14mm
Inch threads range
49kinds 2-40inch
Moudle threads range
11kinds 0.5-3.5mπ
CARRIAGE
Max.travel of top slide
95mm
Max.travel of cross slide
250mm
Max.
