Winding Machine For Winding Inductors, Audio Transformers, Audio Transformers 600: 600 OHM, Output Transformer, Custom Transformers, Power Transformers. in Zhongshan, Guangdong, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Spindle no.
- 1
- Winding speed
- 0-1200rpm (customizable to 6000rpm)
- Winding wire diameter
- 0.1-2.8mm(AWG38-9)
- Winding coil diameter
- 0-360mm(14inch)
- Traverse distance
- 0-400mm(15.7inch)
- Power
- 220v/50-60Hz (customizable)
- Dimension
- 900*500*665MM
- Weight
- 120KG
- Category
- Transformers in China
- Subcategory
- Transformer winders
- Subcategory 2
- Linear transformer winding machine
- Listing ID
- 106190422
Description
winding machine for winding inductors, audio transformers, audio transformers 600: 600 OHM, output transformer, custom transformers, power transformers.
Features
Options/Accessories: • Keyless Chuck Adapter – Tooling (1 required)
Winding machine advantages
1. The use of independent bearing design, toothed belt replacement quick and easy.
2. Power-off save winding data, effectively avoid scrap coil.
3. wind to bobbin end side, intelligent deceleration, can fast winding thick wire.
4. Machine can automatic measure out the start winding data and winding width.
5. Can set the spindle climb time, you can set the winding speed up and down when the machine winding.
6. Full-English touch screen display, the operation more convenient and quick.
7. Using 32-bit ARM control chip controller, faster computing speed, effectively reducing the cable error.
8. All optical input and output isolation, work stability.
9.
