2006 Failing CF-15 in Winnie, TX, USA

- Gardner-Denver 5-1/2” x 8” Duplex Pump

- Item 0562 (A)

- Condition: Used

- Location: Texas, USA

MAST ASSEMBLY :

- Heavy duty deep designed mat 39’ tubular steel, two piece mast.

- Gross capacity 45,000 lbs

- Two deadline anchors in a crown raised and lowered by two mast raising cylinders with safety checks and chrome plated push rods. Wired for electric lights

DRILL FRAME :

- Electric welded structural steel frame with stringers and reinforced cross members, steel tool box located in the drill frame

DRAWWORKS :

- Double drum hoist. Each drum has 8-3/4” spool length and 6” width brake bands mounted on a single drum with individual Wichita 14” three-plate friction clutches controlled by individual brake controls. Single line pull, bare drum 15,000 lbs.

MUD PUMP :

- Gardner Denver 5-1/2” x 8” Duplex pump. 2-1/2” Flow line and stand pipe

AIR COMPRESSOR :

- LeRoi Model 100-SDS two-stage

SUB-DRIVE CASE :

- Multiple roller chains enclosed in a heavy-duty oil-tight case, splash fabricated, ball bearing throughout.

TRANSMISSION :

- Heavy-duty four-speed, single plate 12” rotary clutch ahead of transmission, remote controlled from the driller’s station

ROTARY TABLE :

- 5-5/16” Heavy-duty, hydraulically retractable

ROD RACK :

- Including 27-pcs of new drill pipes. Size: 2-7/8” OD x 20’ L
