Varnish Effect Printing Machine with Large Format Size in Guangdong, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Plate
- Printing
- Structure
- Printing
- Color & page
- Multi-Colour Printing Press
- Printing interface
- USB3.0
- Printing speed
- 30 Square Meter Per Hour
- System supported
- Windowsxp32
- Material thickness
- 180mm to 400mm
- Ink color
- Cmyklclmwv
- Print resolution
- 600*2400dpi
- Print head
- Ricoh Gen5/Ricoh Gen6/I3200/Ricoh Gen5I/ Kyocera
- Print size
- 2500*1300mm
- Printer weight
- 1550kg
- Materials
- Glass, Acrylic, Plastic, Wood, Ceramic, Metal
- Transport package
- Wooden Package
- Specification
- 4550*2796*1570mm
- Hs code
- 8443321300
- Category
- Packaging Machinery in China
- Subcategory
- Printing machinery
- Subcategory 2
- Packaging & printing
- Subcategory 3
- Digital printing machine
- Listing ID
- 92651031
Description
Product Description
YD-P20R5
Printer model YD-P20R5
Print size 2500×1300mm
Print height 180mm
Print head Ricoh Gen5
Number of nozzles 3row 2,3,4,5,6,7,8
Speed High-speed mode 30 square meter /h
Normal mode 23 square meter /h
High resolution mode 15 square meter /h
Color System C,M,Y,K,LC,LC,W,V
ink Eco-friendly UV curing ink(NO VOC)
RIP Software Photoprint RIP Software
Color management International standard ICC
UV curing systems 085 mercury lamp curing, the energy level is adjustable 3-4 / led UV lamp (optional)
Interface mode High speed USB
Power requirement AC220V/4800W;50/60HZ
Working environment the optimum temperature:20ºC-28ºC,Relative humidity:40%-60%
Printer size 4550×2796×1570(mm)
Printer weight 1550KG
Machine Details
Integrated steel frame structure
1.5kw vortex type high pressure air pump fan
Ink circuit negative pressure control system
Intelligent ink mixing system
Ink shortage alarm system and double negative pressure independent system
Import Germany IUGS towline
$20,000 USD
