HZTH5007, 5 Ton telehandler, 5 Ton 7 M Telehandler, 5 Ton 6 M Telehandler, Telehandler with Bucket, Telehandler with Fork, Telehandler with Working Telehandler, Telehandler with Bucket, Telehandler with Fork in Hunan, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Brand
- Hua Drill
- Serial no. s/n
- Name of performance project Performance or parameters 备注Remarks
- Outline dimension
- Length (mm) 5150 Remove the pallet forkRemove the pallet fork
- Width (mm)
- 2250
- Height (mm)
- 2300
- Dead weight (kg)
- 8000
- Hydraulic system pressure (mpa) hydraulic system pressure (mpa)
- 26
- Hydraulic system flow (l/min) hydraulic system flow (l/min)
- 145
- Hydraulic fuel tank capacity (l) hydraulic fuel tank capacity (l)
- 150
- Engine
- Model QSB3.9-C110-30 National Standard III
- Power (kw@rev)power (kw@rev)
- 81/2200
- Torque (n@rev) torque (n@rev)
- 480/1600
- Maximum traveling speed (km/h) maximum mobile speed (km/h)
- 25
- Climbing degree (°) gradability (º)
- 30%
- Departure angle (°) departure angle (º)
- 33
- Rear axle frame swing angle (°) swing angle of rear axle frame (º)
- 5
- Tire specification
- 16.70-20 or 16.70-2416.70-20 or 16.70-24
- Category
- Telehandlers in China
- Listing ID
- 94428201
Description
telehandler 5 ton for Agricultural customers need Power Take Off (PTO), four wheel drive telehandler, Russian customers need hydrostatic drive, Hydraulic systems require closed hydrostatic drive.
Russian customers need hydrostatic drive , Hydraulic systems require closed hydrostatic
Additional oil pipes are needed on the arm as the power source for the attachment.
